HARDWARE INSTALLATION GUIDE
Brocade 300
Hardware Installation Guide
53-1000862-12
29 December 2017

Advertisement

Table of Contents
loading

Related Manuals for Brocade Communications Systems 300

Summary of Contents for Brocade Communications Systems 300

  • Page 1 HARDWARE INSTALLATION GUIDE Brocade 300 Hardware Installation Guide 53-1000862-12 29 December 2017...
  • Page 2 2017 Brocade Communications Systems LLC. All Rights Reserved. Brocade and the stylized B logo are among the trademarks of Brocade Communications Systems LLC. Broadcom, the pulse logo, and Connecting everything are among the trademarks of Broadcom. The term "Broadcom" refers to Broadcom Limited and/or its subsidiaries Brocade, a Broadcom Limited Company, reserves the right to make changes without further notice to any products or data herein to improve reliability, function, or design.

  • Page 3: Table Of Contents

    Command syntax conventions........................................8 Document feedback..............................................8 Device Overview..........................................9 Brocade 300 features..............................................9 Port side of the Brocade 300..........................................10 Non-port side of the Brocade 300......................................... 10 Supported fabric configurations........................................11 Ports on Demand license............................................ 11 ISL trunking groups..............................................11 Managing the Brocade 300..........................................12 Preparing for Installation.........................................13...
  • Page 4 Local time synchronization........................................58 Setting the date...............................................58 Setting time zones............................................58 Synchronizing local time using NTP......................................59 Monitoring the Device........................................61 Powering the Brocade 300 on and off......................................61 Interpreting LED activity............................................61 Brocade 300 LEDs............................................61 LED locations..............................................61 LED patterns..............................................62 POST and boot specifications...........................................63 POST..................................................
  • Page 5 KCC statement (Republic of Korea)......................................... 77 VCCI statement................................................77 Germany..................................................77 Cautions and Danger Notices......................................79 Cautions..................................................79 General cautions.............................................79 Electrical cautions............................................80 Danger Notices................................................ 80 General dangers............................................. 80 Electrical dangers............................................81 Dangers related to equipment weight....................................81 Laser dangers..............................................82 Brocade 300 Hardware Installation Guide 53-1000862-12...
  • Page 6 Brocade 300 Hardware Installation Guide 53-1000862-12...

  • Page 7: About This Document

    Document conventions...................................... 7 • Document feedback......................................8 Supported hardware and software This document is specific to the Brocade 300 SAN switch running Brocade Fabric OS 5.0.1 or later. What’s new in this document • Modified operating temperature range in Brocade 300 Technical Specifications on page 69.

  • Page 8: Text Formatting Conventions

    However, if you find an error or an omission, or you think that a topic needs further development, we want to hear from you. Send your feedback to documentation.pdl@broadcom.com Provide the publication title, part number, and as much detail as possible, including the topic heading and page number if applicable, as well as your suggestions for improvement. Brocade 300 Hardware Installation Guide 53-1000862-12...

  • Page 9: Device Overview

    When functioning as an access gateway, the Brocade 300 provides a single platform for all SAN connectivity. Because the Brocade 300 is scalable, you can use it as a foundation switch for a small SAN and continue to use it as a building block as the SAN grows.

  • Page 10: Port Side Of The Brocade 300

    Non-port side of the Brocade 300 The non-port side of the Brocade 300 is used solely for air flow. There are two labels on the bottom of the chassis. On the right side is the Brocade standard agency label. On the left side is the Brocade standard OEM data label.

  • Page 11: Supported Fabric Configurations

    Ports on Demand license . By default, ports 0 through 7 are enabled on the Brocade 300. To enable ports 8 through 16, install a POD license key. To enable ports 16 through 24, install another POD license.

  • Page 12: Managing The Brocade 300

    Managing the Brocade 300 Managing the Brocade 300 You can use the management functions built into the Brocade 300 to monitor the fabric topology, port status, physical status, and other information to help you analyze switch performance and to accelerate system debugging.

  • Page 13: Preparing For Installation

    • Recommendations for cable management............................15 • Items included with the Brocade 300...............................15 Installation precautions When using this product, observe all danger, caution, and attention notices in this manual. The notices are accompanied by symbols that represent the severity of the safety condition.

  • Page 14: Rtc Battery Precautions

    Laser Radiation. Do Not View Directly with Optical Instruments. Class 1M Laser Products. DANGER Use only optical transceivers that are qualified by Brocade Communications Systems LLC and comply with the FDA Class 1 radiation performance requirements defined in 21 CFR Subchapter I, and with IEC 60825 and EN60825. Optical products that do not comply with these standards might emit light that is hazardous to the eyes.

  • Page 15: Environmental Considerations

    Items included with the Brocade 300 The following items are included with the standard shipment of the Brocade 300. When you open the Brocade 300 packaging, verify that these items are included in the package and that no damage has occurred during shipping: •...
  • Page 16 Items included with the Brocade 300 • An accessory kit containing: – Serial cable with an RJ-45 connector – 6 ft. Power Cord – Rubber feet, required for setting up the switch as a standalone unit Brocade 300 Hardware Installation Guide...

  • Page 17: Mounting The Device

    Installing a standalone Brocade 300 Perform this task to install the Brocade 300 as a standalone unit. Unpack the Brocade 300. Apply the adhesive rubber feet. Applying the rubber feet onto the switch helps prevent the switch from sliding off the supporting surface.

  • Page 18: Eia Rack Considerations

    • #2 Phillips torque screwdriver • 1/4 inch slotted-blade torque screwdriver NOTE You may need two people to install the device, one to support the device, while the other secures it into the rack. Brocade 300 Hardware Installation Guide 53-1000862-12...

  • Page 19: Parts List

    Bracket, front right and back left Screw, 6-32 x 1/4-in., flathead Phillips (8) Bracket, front left and back right Screw, 10-32 x 5/8-in., panhead Phillips (8) Screw, 8-32 x 5/16-in., panhead Phillips (12) Retainer nut, 10-32 (8) Brocade 300 Hardware Installation Guide 53-1000862-12...

  • Page 20: Attaching The Front Brackets To The Device

    Make sure that the airflow for all devices moves in the same direction to maximize cooling. Refer to the Hardware Installation Guide for your product for specific requirements. Brocade 300 Hardware Installation Guide 53-1000862-12...

  • Page 21: Attaching The Device To A Rack

    Position the right rear bracket in the right rear of the device as shown in the following figure. Attach the brackets using three 10-32 x 5/8-in. screws and 10-32 retainer nuts. Repeat step 1 and step 2 to attach the left rear bracket. Brocade 300 Hardware Installation Guide 53-1000862-12...

  • Page 22: Attaching The Rear Brackets To The Device

    Align the left rear bracket to the left rear of the device and use two 8-32 x 5/16-in. screws to attach the bracket to the device as shown in the following figure. Brocade 300 Hardware Installation Guide 53-1000862-12...

  • Page 23: Installing The 1U And 2U Fixed-Mount Rack Kit For Four-Post Racks (Xbr-R000162)

    Allow 15 to 30 minutes to complete the installation procedure. The following items are required to install a device using the 1U and 2U Fixed-Mount Rack Kit for Four-Post Racks (XBR-R000162). • #2 Phillips torque screwdriver • 1/4-inch slotted-blade torque screwdriver Brocade 300 Hardware Installation Guide 53-1000862-12...

  • Page 24: Parts List

    CAUTION Use the screws specified in the procedure. Using longer screws can damage the device. Parts list The following parts are provided with the 1U and 2U Fixed-Mount Rack Kit for Four-Post Racks (XBR-R000162). Brocade 300 Hardware Installation Guide 53-1000862-12...
  • Page 25 Not all parts may be used with certain installations depending on the device type. NOTE Although this document describes how to install single-height (1U) and double-height (2U) devices, the illustrations show a single-height device as a typical installation. Brocade 300 Hardware Installation Guide 53-1000862-12...

  • Page 26: Attaching The Front Brackets

    Repeat step 1 through step 3 to attach the left front bracket to the left side of the device. Tighten all the 8-32 x 5/16-in. screws to a torque of 15 in-lbs (17 cm-kgs). FIGURE 10 Attaching the front brackets Bracket, front right Screw, 8-32 x 5/16-in., panhead Phillips Brocade 300 Hardware Installation Guide 53-1000862-12...

  • Page 27: Installing The Device In The Rack

    Attach the right front bracket to the right front rack post using two 10-32 x 5/8-in. screws and two retainer nuts. Attach the left front bracket to the left front rack post using two 10-32 x 5/8-in. screws and two retainer nuts. Brocade 300 Hardware Installation Guide 53-1000862-12...

  • Page 28: Attaching The Rear Brackets To The Front Brackets

    Complete the following steps to attach the rear brackets to the front brackets. Position the right rear bracket inside the right front bracket, as shown in the following figure. Attach the brackets using four 6-32 x 1/4-in. screws. Brocade 300 Hardware Installation Guide 53-1000862-12...

  • Page 29: Attaching The Rear Brackets To The Rack Posts

    Attach the right rear bracket to the right rear rack post using two 10-32 x 5/8-in. screws and two retainer nuts, as shown in the following figure. Attach the left rear bracket to the left rear rack post using two 10-32 x 5/8-in. screws and two retainer nuts. Brocade 300 Hardware Installation Guide 53-1000862-12...

  • Page 30: Slide Rack Mount Kit (Xbr-R000070)

    Before mounting your device, review any specific installation and facility requirements in this Hardware Installation Guide. • Hardware devices illustrated in these procedures are only for reference and may not depict the device you are installing into the rack. Brocade 300 Hardware Installation Guide 53-1000862-12...

  • Page 31: Safety Precautions

    The following parts are provided with the 1U and 2U Slide-Mount Rack Kit for Four-Post Racks (XBR-R000070). NOTE Use the screws specified for use with the device. Longer screws can damage the device. NOTE Depending on the device type, not all parts may be used in an installation. Brocade 300 Hardware Installation Guide 53-1000862-12...
  • Page 32 3, 4, and 5 installed on the outer slide rail (each slide assembly is bagged separately) (2) FIGURE 15 Rack kit parts(2 of 4) Phillips screw, 10-32 x 1/2 in., black (12) Alignment washer (12) Three-hole rack nut bar, 8-32 (4) Retainer nut, 10-32 (12) Brocade 300 Hardware Installation Guide 53-1000862-12...

  • Page 33: Installing The Device

    Locate the slide assembly in the kit, as shown in the following figure. The slide assembly comes fully assembled and includes all of the parts shown in the figure. Pull the inner slide rail out until the lock engages. Refer to the following figure. Brocade 300 Hardware Installation Guide 53-1000862-12...
  • Page 34 NOTE The hole pattern is identical for all 1U, 1.5U, and 2U devices. Attach the rail using three Phillips 8-32 x 3/16-in. screws. Tighten the screws to a torque of 15 in-lbs (17 cm-kgs). Brocade 300 Hardware Installation Guide 53-1000862-12...
  • Page 35 For recessed mounting, you can use the back rack mount brackets on the front instead of the left and right rack mount brackets. Tighten the screws to a torque of 15 in-lbs (17 cm-kgs). Brocade 300 Hardware Installation Guide 53-1000862-12...
  • Page 36 Perform the following steps to reposition the port side L-bracket for correct mounting. On the port side of the outer slide rail, using the 11/32-inch wrench, loosen the nuts securing the L-bracket, as shown in the following figure. Brocade 300 Hardware Installation Guide 53-1000862-12...
  • Page 37 Leave the middle hole empty on the port side for securing the rack mount bracket later (refer to Inserting the device in the rack on page 42). Tighten the screws to 15 in-lbs (17 cm-kgs). Brocade 300 Hardware Installation Guide 53-1000862-12...
  • Page 38 Perform the following steps to install the square-hole hardware using Method A. Position the outer slide rail inside the rack posts with the closed ends of the slide rail toward the non-port side of the rack, as shown in the following figure. Brocade 300 Hardware Installation Guide 53-1000862-12...
  • Page 39 Leave the middle hole empty on the port side for securing the rack mount bracket later (refer to Inserting the device in the rack on page 42). Tighten the screws to 15 in-lbs (17 cm-kgs). Brocade 300 Hardware Installation Guide 53-1000862-12...
  • Page 40 Perform the following steps to install the square-hole hardware using Method B. Position the outer slide rail inside the rack posts with the closed ends of the slide rail toward the non-port side of the rack, as shown in the following figure. Brocade 300 Hardware Installation Guide 53-1000862-12...
  • Page 41 Three-hole slide mount L-bracket Three-hole slide mount L-bracket (2 each side) Alignment washer (6 each side) Rack post (port side) Rack post (non-port side) Outer slide rail Three-hole rack nut bar, 8-32 (2 each side) Brocade 300 Hardware Installation Guide 53-1000862-12...
  • Page 42 Ensure that the clips do not interfere with the movement of the rails. Position all the clips either with the tabs above or with the tabs below the rail. FIGURE 25 Attaching the power cord clips Three-hole slide mount L-bracket Power cord clips (3 each side) Slide assembly Brocade 300 Hardware Installation Guide 53-1000862-12...
  • Page 43 FIGURE 26 Inserting the power cords in clips Power cord Slide assembly Position the device next to the rack; align and insert the inner rails inside the outer rails, as shown in the following figure. Brocade 300 Hardware Installation Guide 53-1000862-12...
  • Page 44 Check the rail alignment by sliding the device out and back into the rack. FIGURE 27 Inserting the device device Slide assembly open end Slide assembly closed end Inner slide rail Outer slide rail Lock-release lever Brocade 300 Hardware Installation Guide 53-1000862-12...
  • Page 45 FIGURE 28 Securing rack mount brackets for round-hole rack posts Right rack mount bracket Three-hole rack nut bar, 8-32 Rack post Phillips screw, 10-32 x 1/2 in., black FIGURE 29 Method A for securing rack mount brackets for square-hole rack posts Brocade 300 Hardware Installation Guide 53-1000862-12...
  • Page 46 Slide Rack Mount Kit (XBR-R000070) Right rack mount bracket Retainer nut, 10-32 Rack post Phillips screw, 10-32 x 1/2 in., black Three-hole slide mount L-bracket FIGURE 30 Method B for securing rack mount brackets for square-hole rack post Brocade 300 Hardware Installation Guide 53-1000862-12...

  • Page 47: Installing The 1U And 2U Non-Port Side Fixed-Mount Rack Kit (15"-20") For Four-Post Racks (Xna-000072 And Xna-100072)

    Two people are required to install the device in a rack. One person holds the device, while the other secures the device to the rack. • Before mounting your device, review any specific installation and facility requirements in this Hardware Installation Guide. Brocade 300 Hardware Installation Guide 53-1000862-12...

  • Page 48: Time And Items Required

    Use the screws specified in the procedure. Using longer screws can damage the device. Parts list The following parts are provided with the 1U and 2U Non-Port Side Fixed-Mount Rack Kit (15"-20") for Four-Post Racks (XNA-000072 and XNA-100072). Brocade 300 Hardware Installation Guide 53-1000862-12...

  • Page 49: Attaching The Front Brackets

    The device must be turned off and disconnected from the fabric during this procedure. Complete the following steps to attach the front brackets to the device. NOTE Pay particular attention to the labeling on the brackets. Brocade 300 Hardware Installation Guide 53-1000862-12...
  • Page 50 Refer the following figure. There are four pairs of vertically aligned holes in the brackets. Each pair is labeled with a letter as are a number of single holes along the length of the bracket. Each letter corresponds to a specific device's mounting holes. For the Brocade 300 use the holes marked with the letter ‘A’. NOTE Example illustrations in the following procedures may show the screws inserted in holes designated for devices other than the device that you are installing.

  • Page 51: Installing The Device In The Rack

    Attach the right front bracket to the right front rack post using two 10-32 x 5/8-in. screws and two retainer nuts. Select the correct nuts for either square or round holes in the rack posts. Brocade 300 Hardware Installation Guide 53-1000862-12...

  • Page 52: Attaching The Rear Brackets To The Front Brackets

    Attach the brackets using four 6-32 x 1/4-in. screws as shown in the following figure. Adjust the brackets to the rack depth and tighten the 6-32 x 1/4-in. screws to a torque of 9 in-lb (10 cm-kg). Brocade 300 Hardware Installation Guide 53-1000862-12...

  • Page 53: Attaching Rear Brackets To The Rack Posts

    Attach the right rear bracket to the right rear rack post using two 10-32 x 5/8-in. screws and two retainer nuts as shown in the following figure. Select the correct retainer nuts for either square or round holes in the rack posts. Brocade 300 Hardware Installation Guide 53-1000862-12...
  • Page 54 10-32 x 5/8-in. screws to a torque of 25 in-lb (29 cm-kg). FIGURE 36 Attaching the rear bracket to the rack post Bracket, front right Retainer nuts, 10-32, square or round holes as needed Bracket, rear right Screws, 10-32 x 5/8 in., panhead Phillips Brocade 300 Hardware Installation Guide 53-1000862-12...

  • Page 55: Initial Setup And Verification

    Date and time settings.....................................57 Once you have set up the Brocade 300 in a rack or as a standalone switch, it is time to give it power and a basic configuration. If you are going to use the Brocade 300 in a single-switch setup, you can use EZSwitchSetup to complete the basic configuration.

  • Page 56: Creating A Serial Connection

    Setting the switch IP address You can configure the Brocade 300 with a static IP address, or you can use a DHCP (Dynamic Host Configuration Protocol) server to set the IP address of the switch. DHCP is enabled by default. The Brocade 300 supports both IPv4 and IPv6.

  • Page 57: Date And Time Settings

    The Brocade 300 maintains the current date and time inside a battery-backed real-time clock (RTC) circuit. Date and time are used for logging events. Switch operation does not depend on the date and time; a Brocade 300 with an incorrect date and time value still functions properly.

  • Page 58: Local Time Synchronization

    You must perform the procedure on all switches for which the time zone must be set. However, you only need to set the time zone once on each switch, because the value is written to nonvolatile memory. Use one of the two following procedures to set the time zone. Brocade 300 Hardware Installation Guide 53-1000862-12...

  • Page 59: Synchronizing Local Time Using Ntp

    At the prompt, enter the appropriate number to specify the time zone region or Ctrl-D to quit. Synchronizing local time using NTP Perform the following steps to synchronize the local time using NTP. Log into the switch using the default password, which is password. Brocade 300 Hardware Installation Guide 53-1000862-12...
  • Page 60 The following example shows how to set up more than one NTP server using a DNS name: switch:admin> tsclockserver "10.32.170.1;10.32.170.2;ntp.localdomain.net" Updating Clock Server configuration...done. Updated with the NTP servers Changes to the clock server value on the principal or primary FCS switch are propagated to all switches in the fabric. Brocade 300 Hardware Installation Guide 53-1000862-12...

  • Page 61: Monitoring The Device

    Powering the Brocade 300 on and off To power on the Brocade 300, connect the power cable to the AC receptacle on the switch and to a power source. The switch runs POST by default each time it is powered on, reset, or rebooted, and requires a up to three minutes to run.

  • Page 62: Led Patterns

    E. Port status LED for port 3 F. Port status LED for port 7 LED patterns The following table summarizes the state of the Brocade 300 LEDs as well as recommended user responses. TABLE 3 Brocade 300 LED Patterns During Normal Operation LED Name...

  • Page 63: Post And Boot Specifications

    POST and boot specifications TABLE 3 Brocade 300 LED Patterns During Normal Operation (continued) LED Name LED Color Status of Hardware Recommended Action Contact Technical Support. Flashing amber/green Attention is required. A number of Check the management interface variables can cause this status...

  • Page 64: Post

    For information about error messages, refer to the Fabric OS Message Reference Manual . Maintaining the Brocade 300 The Brocade 300 does not require any regular physical maintenance; it was designed to minimize the chance of failure. Brocade 300 Hardware Installation Guide...

  • Page 65: Installing An Sfp

    Installing an SFP The Brocade 300 supports only Brocade-branded SFPs. If you use an unqualified SFP, the switchShow command output shows the port in a Mod_Inv state. Fabric OS also logs the issue in the system error log.

  • Page 66: Diagnostic Tests

    Laser Radiation. Do Not View Directly with Optical Instruments. Class 1M Laser Products. DANGER Use only optical transceivers that are qualified by Brocade Communications Systems LLC and comply with the FDA Class 1 radiation performance requirements defined in 21 CFR Subchapter I, and with IEC 60825 and EN60825.

  • Page 67: Field Replaceable Units (Frus)

    For information about specific diagnostic tests, refer to the Fabric OS Troubleshooting and Diagnostics Guide . Field Replaceable Units (FRUs) In the Brocade 300, the only parts that are field replaceable are the SFPs. The entire switch is a FRU. The fan units and power supply are not field replaceable in this switch.
  • Page 68 Brocade 300 Hardware Installation Guide 53-1000862-12...

  • Page 69: Brocade 300 Technical Specifications

    The Brocade 300 SAN Switch is a cost-effective and highly-scalable 1, 2, 4, or 8 Gbps switch, designed for small to mid-sized businesses. The Brocade 300 SAN Switch is a dual purpose device that you can use either as a full-functioned switch or as an N_Port ID Virtualization (NPIV) access gateway.

  • Page 70: Other

    Maximum inrush power rating (DC) current current Not available 75 W 100 - 240 VAC 50/60 Hz (nominal) 2.0 A 21.5 A separately (nominal) 47 - 63 Hz (range) 90 - 264 VAC (range) Brocade 300 Hardware Installation Guide 53-1000862-12...

  • Page 71: Power Consumption

    860 m (2,821 ft) (OM3) 62.5 300 m (984 ft) 10 km (6.2 miles) 40 km (24.8 miles) 300 m (984 ft) (OM2) 500 m (1,640 ft) (OM3) 62.5 150 m (492 ft) 40 km (24.8 miles) 150 m (492 ft) (OM2) 380 m (1,246 ft) (OM3) 62.5...

  • Page 72: Serial Port Specifications (Protocol)

    EM 55032 (CE Mark) (Class A) • ICES-003 • VCCI • EN 300 386 • CNS 13438 • KN 32 • KN 35 • TCVN 7189 • EN 61000-3-2 • EN 61000-3-3 • GB 9254 • CISPR 32 Brocade 300 Hardware Installation Guide 53-1000862-12...

  • Page 73: Regulatory Compliance (Safety)

    Section 1502 of the Dodd-Frank Wall Street Reform and Consumer Protection Act of 2010 - U.S. Conflict Minerals. • 30/2011/TT-BCT - Vietnam circular. • SJ/T 11363-2006 Requirements for Concentration Limits for Certain Hazardous Substances in EIPs (China). • SJ/T 11364-2006 Marking for the Control of Pollution Caused by EIPs (China). Brocade 300 Hardware Installation Guide 53-1000862-12...
  • Page 74 Brocade 300 Hardware Installation Guide 53-1000862-12...

  • Page 75: Regulatory Statements

    European Council directives, laws, and standards: • Electromagnetic Compatibility (EMC) Directive 2014/30/EU • Low Voltage Directive (LVD) 2014/35/EU • EN 55032/EN 55024 (European Immunity Requirements) – EN61000-3-2/JEIDA (European and Japanese Harmonics Spec) – EN61000-3-3 Brocade 300 Hardware Installation Guide 53-1000862-12...

  • Page 76: China Ccc Statement

    This equipment has been tested and complies with the limits for a Class A computing device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. Brocade 300 Hardware Installation Guide 53-1000862-12...

  • Page 77: Kcc Statement (Republic Of Korea)

    Machine noise information regulation - 3. GPSGV, the highest sound pressure level value is 46.7 dB(A) in accordance with EN ISO 7779. Maschinenlärminformations-Verordnung - 3. GPSGV, der höchste Schalldruckpegel beträgt 47.7 dB(A) gemäss EN ISO 7779. Brocade 300 Hardware Installation Guide 53-1000862-12...
  • Page 78 Brocade 300 Hardware Installation Guide 53-1000862-12...

  • Page 79: Cautions And Danger Notices

    PRECAUCIÓN Si se realizan cambios o modificaciones en este dispositivo sin la autorización expresa de la parte responsable del cumplimiento de las normas, la licencia del usuario para operar este equipo puede quedar anulada. Brocade 300 Hardware Installation Guide 53-1000862-12...

  • Page 80: Electrical Cautions

    Die Vorgehensweisen in diesem Handbuch sind für qualifiziertes Servicepersonal bestimmt. DANGER Les procédures décrites dans ce manuel doivent être effectuées par un personnel de maintenance qualifié. PELIGRO Los procedimientos de este manual deben llevarlos a cabo técnicos cualificados. Brocade 300 Hardware Installation Guide 53-1000862-12...

  • Page 81: Electrical Dangers

    Make sure the rack housing the device is adequately secured to prevent it from becoming unstable or falling over. GEFAHR Stellen Sie sicher, dass das Gestell für die Unterbringung des Geräts auf angemessene Weise gesichert ist, so dass das Gestell oder der Schrank nicht wackeln oder umfallen kann. Brocade 300 Hardware Installation Guide 53-1000862-12...

  • Page 82: Laser Dangers

    レーザ放射 光学器具で直接ビームを見ないこと クラス１ M レーザ製品 DANGER Use only optical transceivers that are qualified by Brocade Communications Systems LLC and comply with the FDA Class 1 radiation performance requirements defined in 21 CFR Subchapter I, and with IEC 60825 and EN60825. Optical products that do not comply with these standards might emit light that is hazardous to the eyes.
