Assigning The Ip Address; Using The Scu To Connect To The Wlan - Psion Teklogix Vehicle-Mount Computer 8515 User Manual

Chapter 2: Basic Checkout

Assigning The IP Address

Note:
2.8.1

Assigning The IP Address

Before launching the SCU, you need to configure how the IP address will be obtained.
• Tap on Start>Settings>Network and Dial-up Connections.
Follow the steps under the heading
how the IP address will be obtained—either via DHCP or by specifying an address.
2.8.2

Using The SCU To Connect To The WLAN

This section provides a quick set of steps to create a profile (referred to as a config). Detailed
information about each of the SCU tabs—Main, Config, Status, Diags and Global Set-
tings—is provided under
To launch the SCU so that your vehicle-mount can connect to a wireless LAN:
• Tap on Start>Programs>Summit>SCU.
Figure 2.11 SCU Main Menu
• Tap on the Config tab.
Figure 2.12 SCU Configuration Menu
Radio
Attributes
18 Psion Teklogix 8515 Vehicle-Mount Computer User Manual
You do not need to reset your 8515 after configuring the Summit DC 802.11
SC (Model RA2041) CF radio.
"SCU Tabs"
"Assigning An IP Address" on page 15
beginning on page
to determine
20.
