Note:
7.1
8515 Vehicle-Mount Computer Specifications
Size
203 mm x 209 mm x 50 mm (7.99"x 8.23" x 1.97")
Weight
Approximately 1.3 kg (2.8 lbs)
Environmental
Standard Temperature Unit
Operating Temperature
Storage Temperature
Rain And Dust Resistance
Humidity (operating)
Shock and Vibration testing
Operating System
Microsoft
Processor And Memory
XScale PXA270 @ 312 MHz Processor.
RAM: 128 MB SDRAM standard.
Flash ROM: 128 MB micro-SD card standard (not user-accessible).
Communication Ports
UART (DB-9) port
Two USB V 1.1 host ports
Performance specifications are nominal and subject to change without notice.
®
®
Windows
Embedded CE 5.0
8515 Vehicle-Mount Computer Specifications
-10° C to 50° C (14° F to 122° F)
-35° C to 70° C (-31° F to 158° F)
IEC 529, classification IP65
5% to 90% RH non-condensing at 40° C (104° F)
IEC 60721-3-5 - Class 5M2
RS-232 serial port for decoded scanner, printer
Data rate: 2,400 bps to 115,200 bps
Power: 1000mA @ 5V
For external devices, console
Data rate: 12 Mbps
Power out, +5 VDC @ 500mA nominal
Psion Teklogix 8515 Vehicle-Mount Computer User Manual
Chapter 7: Specifications
143
