Summary of Contents for Gorenje E52103AW
- Page 2 Dear customer, You have purchased a product of our new series of electric ranges. We wish that our product would do you a good turn. We recommend you to study these instructions and to operate this product according to instructions. IMPORTANT INFORMATION ...
-
Page 3: Control Panel
CONTROL PANEL 1. Left front hot plate control knob 2. Left rear hot plate control knob 3. Right rear hot plate control knob 4. Right front hot plate control knob 5. Temperature selector 6. Oven function knob 7. Thermostat function signal lamp 8. - Page 4 RECOMENDATION FOR USING OF ELECTRIC HOT PLATES Use the pots with flat base of a diameter at least equal to that of hot plate, so you reach maximum efficiency. When cooking cover pots if possible. Use accumulated heat in the plate, switch it off some time before end of cooking. ...
- Page 5 OVEN FUNCTIONS AND APPLICATIONS Oven illumination being on in setting up all the oven functions Static oven heat by means of the top and botton heaters. The thermostat can be set to a temperature within 50 – 250° C. Bottom heater in operation. The temperature selector can be set anywhere between 50° C – 250° C. Tip: This function is used for baking which requires high temperature from below.
- Page 6 FOOD GRILLING Grilling with the oven door shut. The position of grid depends on the mass and the type food. As a general rule the grid should be placed in top level guide. GRILLING MEAT ON A GRID ...
- Page 7 OVEN Procedure for cleaning of internal glass door.
- Page 8 CLAIMS If there is any defect on the appliance with in the guarantee period, do not repair itself. Apply a claim in the shop in which you bought the appliance or at servicere presentatives, mentioned in theGuarantee conditions. At applying of claim observe the text of Guarantee sheet and Guarantee conditions. The claim is valid with submitte ddully filled up Guarantee sheet only.
-
Page 10: Important Notice
IMPORTANT NOTICE At any electric range disassembly or assembly besides its current use it is necessary to disconnect the appliance from mains and to keep it out of service. In installation of the appliance, it is necessary to do in the light of its duty chiefly the following: ... -
Page 11: Installation Procedure
Level the cooker using a screwdriver from the receptacle area, or by turning the leveling screw with a hexagon wrench; The procedure is less complicated if performed by using leveling screws. NOTE: Leveling screws are unnecessary if the appliance height and horizontal position are acceptable. WARNING!! In order to prevent tipping of the appliance, this stabilizing means must be installed. -
Page 12: Technical Data
TECHNICAL DATA Electric Cooker E52103AW Dimensions: Height / Depth / Weight 850 / 500 / 605 mm Cooking plate Electric hot plates Left rear Ø 145 mm (kW) Left front Ø 180 mm (kW) Right rear Ø 180 mm (kW) Right front Ø... -
Page 13: Information Table
INFORMATION TABLE Model E52103AW A – More efficient G – Less efficient 0,78 Energy consuption Time to cook standard load 49,2 Energy consuption Time to cook standard load Usable volume (litres) Usable volume: SMALL MEDIUM LARGE Noice (dB) Min. energy consuption (standby) (W)
