Summary of Contents for Realfiction Dreamoc Scandinavia 180

  • Page 2 4 When receiving the Dreamoc Scandinavia 180 p. 4 Package contents p. 5 How to start using the Dreamoc Scandinavia 180 p. 6 How to insert/change the content in the Dreamoc p. 7 Cleaning the Dreamoc Scandinavia 180 p. 8 How to place an object inside the Dreamoc p.

  • Page 3: Eu-Declaration Of Conformity

    Sankt Annæ Plads 13, 5 DK-1250 Copenhagen K Hereby declares that the Dreamoc Scandinavia 180 meets the Council Directive 2006/05/EF of December 12, 2006 (low voltage). Dreamoc is designed to display and promote products along with an electronic produced and animated colour show.

  • Page 4: Security Precautions

    Security precautions Installation of the Dreamoc must be done according to this manual, and must be performed by an adult (Over 21 years). The Dreamoc must be placed on a horizontal, stable and plane surface. The floor stand must be fitted with sufficient ballast as described in this manual. Do not install the Dreamoc in narrow passageways or other places where a lot of people and equipment has to pass close by, thereby risking collisions that might cause the Dreamoc to tip over causing human injuries and damage to...

  • Page 5: Product Guarantee

    This product should not be mixed with other commercial wastes for disposal. When receiving the Dreamoc Scandinavia 180 Please be careful when unpacking the Dreamoc. Especially the optic is a highly precise component.

  • Page 6: Package Contents

    3. White cotton gloves for handling the optic 4. Cleaning cloth – gentle dry use is best 5. 5m power cord with European Schuko plug (C13 PC type cable) 6. A set with two keys for the Dreamoc Scandinavia 180 door...

  • Page 7: How To Start Using The Dreamoc Scandinavia 180

    How to start using the Dreamoc Scandinavia 180 To keep the display in a pristine condition, we have included a set of white cotton gloves to be used when handling the Dreamoc. This prevents setting too many finger marks on the surface. Should this happen anyway, the housing can be cleaned with a damp cloth.

  • Page 8: How To Insert/Change The Content In The Dreamoc

    NOTE: To insert the power cable, place the Dreamoc Scandinavia 180 gently with the front down, to make the bottom visual. Wait about 20 seconds. The Dreamoc is delivered with a pre-installed movie, which will start automatically. The Dreamoc can operate 24/7, but if you would like to turn off the power, you can either use the on/off switch or simply cut power to the Dreamoc.

  • Page 9: Cleaning The Dreamoc Scandinavia 180

    Never use stump objects to remove dirt from the optic. How to place an object in the Dreamoc Scandinavia 180 Placing your actual product or another physical object inside the display creates a very effective mix of reality and fiction! So we urge people to incorporate physical items in the storytelling whenever possible.

  • Page 10: How To Change The Led Light

    NOTE: The lamp becomes hot during operation, so be sure to turn off the display and let it cool about 10 minutes before handling the LED lamp. The LED light is pre-installed in the Dreamoc Scandinavia 180, thus it should not be manually installed after purchase. But should you need to change the...
  • Page 11 Insert the new lamp and refit the metal spring securely. OPTIONAL: The Dreamoc Scandinavia 180 has a standard MR11 socket for G4 LED lamps, which makes it easy to change the light to smoother/brighter LED lamps or change the color of the light, by replacing the original LED...

  • Page 12: How To Access The Lcd Display

    Normally there is no need to access the display. But should this be required please do the following: To access the LCD display the top of the Dreamoc Scandinavia 180 should be lifted up vertically. But first you need to release the internal locks holding it in place.

  • Page 13: Troubleshooting

    Troubleshooting Problem (General) Solution No power. - Make sure the AC outlet has power. - Make sure that the power cable is properly inserted. - Check that the on/off (I/O) button is at I. - Open the bottom chamber and check connections.
