- Page 1 On the following pages it is shown how to update a Dreamoc HD with a Dreamoc HD2 LCD screen. Package contents. 1. Dreamoc HD2 LCD panel. 2. +12 V DC power supply. 3. Power cord. Step 1. Remove the power from Dreamoc HD.
- Page 2 Step 2. Remove, back cover and bottom plate. NOTE: Once opened the backdoor should be taken completely off to avoid damage! Step 3. Remove the top cover.
- Page 3 Don’t throw them out, you might need them later in step 11 (If these small plastic parts are not removed, it will not be possible to fit the Dreamoc HD2 LCD screen in to the top of Dreamoc HD.) Step 6.
- Page 4 Step 8. Pull the old power cable out of Dreamoc HD, and make sure that the + 12V DC plug comes up to the top of the Dreamoc HD. This is very important because the +12C DC plug have to connected to the Dreamoc HD2 LCD panel in the top of the Dreamoc HD.
- Page 5 Step 11. In some Dreamoc HD’s (not all) it can be necessary to use the plastic parts from step 5 to make sure the screen fits properly to the tray. Assemble the top cover, bottom plate and back cover again. Now the Dreamoc HD is updated with...
