Domestic technology

Replacing the door gasket

The door seal is fitted in a groove on the cooking
cabinet.
- Remove the old gasket from the groove.
- Clean the groove rail.
- Insert new gasket into the groove (moisten the
retaining lips with soapy water).
- The rectangular part of the gasket must be seated
fully in the holding frame.
Press-fit door gasket:
6 x 2/3 GN
6 x 1/1 GN
6 x 2/1 GN
10 x 1/1 GN
10 x 2/1 GN
20 x 1/1 GN
20 x 2/1 GN
Replacing the lamps
LED lighting
To replace the LED lighting, please contact your authorised RATIONAL Service Partner.
Changing the halogen lamp
First switch off the appliance at the mains.
- Cover the appliance drain in the cooking cabinet.
- Remove the frame with glass and gasket.
- Replace halogen bulb (no.: 3024.0201), do not
touch the bulb with your hands).
- Replace gasket frame as well (no.: 40.00.094).
- Remove the frame with glass and gasket.
98 / 107
No. 20.02.549
No. 20.02.550
No. 20.02.551
No. 20.02.552
No. 20.02.553
No.: 20.00.398
No.: 20.00.399
