LAN cable connection
Danger of burns.
When laying the LAN cable underneath the unit floor, make sure they do not come in contact
with hot components
Do not wrap the LAN cable around hot components.
The assembly and splash protection can only be guaranteed if you use an Ethernet cable with
the following specifications:
Maximum plug length of the Ethernet plug 45 mm
Maximum plug diameter diagonally of 18.5 mm
Cable diameter 5.5 - 7.5 mm
To ensure full functionality of the interface, a CAT-6 network cable must be used.
For a Combi-Duo installation, the two LAN cables must be installed by a Service Technician.
