- Page 1 HZ030400TX Starlynn Bar Cabinet For assistance with assembly, contact: Southern Enterprises, Inc. Customer Service: 1-800-633-5096 Assembly Instructions service@seidal.com www.seifurniturestore.com PO#: Page | 1...
- Page 2 Starlynn Bar Cabinet Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or a blanket. Check that you have all parts indicated. Call customer service if any hardware is missing.
- Page 3 Quantity Quantity Quantity of 1 of 1 of 2 Right Side Panel of left door Left Side Panel of right door Shelf Panel frame frame Quantity Quantity Quantity of 2 of 2 of 1 Check Rails Bottom Panel of Door Frame Left Door Top Panel Quantity Quantity...
- Page 4 Care and Cleaning Instructions: Before using, wipe with a clean, dry cloth. For replacement parts or questions, please call Avoid rubbing or scratching the surface with SEI Customer Service at 1-800-633-5096. rough or abrasive objects. Assembly Tool Required: No.2 Phillips Screwdriver, Hammer...
- Page 5 Starlynn Bar Cabinet Assembly Instructions Align Cam Bolts (A) by hand. Insert Cam Locks (B) into corresponding holes on Upper Back Panel (5). Please do not overtighten cam locks. Stop when they feel secure. Screw Cam Bolts (A) into threaded holes on Shelf Panel (4).
- Page 6 Align Cam Bolts (A) by hand. Insert Cam Locks (B) into corresponding holes on pre-assembled unit from figure 2. Screw Cam Bolts (A) into threaded holes on Top Panel (1). Attach Top Panel (1) to pre-assembled unit from figure 2 by inserting Cam Bolts (A) and Wood Dowels (C) into corresponding holes until all panels meet.
- Page 7 Attach 3 Legs (7) to the Middle Top Panel (6) with Bolts (M), Spring Washers (E), and Flat Washers (F). Tighten bolts with Allen Wrench (G). Figure 5 Attach Bottom Panel (20) to the pre-assembled unit from Figure 5 with Bolts (D), Brackets (N), Spring Washers (E), and Flat Washers (F).
- Page 8 Attach the fourth Leg (7) to pre-assembled unit from Figure 6 with Bolts (D), Brackets (N), Spring Washers (E), and Flat Washers (F). Tighten bolts with Allen Wrench (G). Figure 7 Attach the Middle Panel (8) to pre-assembled unit from Figure 7. Figure 8 Page | 8...
- Page 9 Attach Back Panels (9) to back of the unit with Screws (H). Tighten Screws (H) with Phillips screwdriver (not included) Figure 9 Align Cam Bolts (A). Insert Cam Locks (B) into corresponding holes on Check Rail (16). Screw Cam Bolts (A) into threaded holes on Shelf Panel (15).
- Page 10 Align Cam Bolts (A) by hand. Insert Cam Locks (B) into corresponding holes on 1 pre-assembled unit from Figure Screw Cam Bolts (A) into threaded holes on Side Panel of Door Frame (11/13). Attach Side Panel of Door Frame (11/13) to pre-assembled unit from Figure 10 by inserting Cam Bolts (A) and Wood Dowels (C) into corresponding holes until all...
- Page 11 Align Cam Bolts (A) by hand. Insert Cam Locks (B) into corresponding holes on pre-assembled unit from figure Screw Cam Bolts (A) into threaded holes on Left Door Panel (10). Attach Left Door Panel (10) to pre-assembled unit from figure 12 by inserting Cam Bolts (A) and Wood Dowel (C) into corresponding holes until all panels meet.
- Page 12 Align Cam Bolts (A) by hand. Insert Cam Locks (B) into corresponding holes on pre-assembled unit from Figure Screw Cam Bolts (A) into threaded holes on Right Door Top Panel (19). Attach Right Door Top Panel (19) to pre-assembled unit from Figure 14 by inserting Cam Bolts (A) and Wood Dowels (C) into corresponding holes until all panels meet.
- Page 13 Align Screws (O) by hand. Attach the assembled doors from Figures 13 & 16 to pre-assembled unit from Figure 9 with Screws (O). Tighten Screws (O) with Phillips screwdriver (not included). Attach the Knobs (J) & Gaskets (K) to the doors with Bolts (L).
- Page 14 Move the unit close to the fastened wall bracket (Q) and tie in both brackets with plastic straps (P). Warning: Anti-tipping hardware must be used for this product to avoid tipping and injury. Figure 19 Now your Starlynn Bar Cabinet is ready to use.
- Page 15 Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
