HZ030300TX
Kismet Multi-Finish Cabinet
For assistance with assembly, contact:
Southern Enterprises, Inc.
Customer Service: 1-800-633-5096
Assembly Instructions
service@seidal.com
www.seifurniturestore.com
PO#:
Page | 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Kismet Multi-Finish Cabinet HZ030300TX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SEI Kismet Multi-Finish Cabinet HZ030300TX

Summary of Contents for SEI Kismet Multi-Finish Cabinet HZ030300TX

  • Page 1 HZ030300TX Kismet Multi-Finish Cabinet For assistance with assembly, contact: Southern Enterprises, Inc. Customer Service: 1-800-633-5096 Assembly Instructions service@seidal.com www.seifurniturestore.com PO#: Page | 1...

  • Page 2: Parts List

    Kismet Multifinish Cabinet Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or a blanket. Check that you have all parts indicated. Call customer service if any hardware is missing.
  • Page 3 Quantity Quantity Quantity of 4 of 4 of 2 Drawer Bottom Panel Back Panel Metal Frame Quantity Quantity of 2 of 2 Top Stretcher Bottom Stretcher Quantity Quantity Quantity of 32 of 32 of 32 Cam Bolts Cam Locks Wood Dowels Dia.
  • Page 4 Care and Cleaning Instructions: Before using, wipe with a clean, dry cloth. For replacement parts or questions, please call Avoid rubbing or scratching the surface with SEI Customer Service at 1-800-633-5096. rough or abrasive objects. Assembly Tool Required: No.2 Phillips Screwdriver, Hammer...
  • Page 5 Kismet Multifinish Cabinet Assembly Instructions Align Bolts (D) by hand. Attach the Metal Frames (15) to Top Stretchers (16) and Bottom Stretchers (17) with Bolts (D), Spring Washers (E), and Flat Washers (F). Tighten Bolts (D) with Allen Wrench (G). Figure 1 Attach the assembled unit from Figure1 to the Bottom Panel (4)
  • Page 6 Align Cam Bolts (A) by hand Insert Cam Locks (B) into corresponding holes on Side Please do not overtighten cam locks. Stop when they feel secure. Panels (2/3). Screw Cam Bolts (A) into threaded holes on Bottom Panel (4). Attach Side Panels (2/3) to Bottom Panel (4) by inserting Cam Bolts (A) and Wood Dowels (C) into corresponding holes until all...
  • Page 7 Align Cam Bolts (A) by hand. Insert Cam Locks (B) into corresponding holes on Side Panels (2/3). Screw Cam Bolts (A) into threaded holes on Lower Shelf Panel (6). Attach Side Panels (2/3) to Lower Shelf Panel (6) by inserting Cam Bolts (A) and Wood Dowels (C) into corresponding holes until all panels meet.
  • Page 8 Align Cam Bolts (A) by hand. Insert Cam Locks (B) into corresponding holes on Side Panels (2/3). Screw Cam Bolts (A) into threaded holes on Upper Shelf Panel (5). Attach Side Panels (2/3) to Upper Shelf Panel (5) by inserting Cam Bolts (A) and Wood Dowels (C) into corresponding holes until all panels meet.
  • Page 9 Align Cam Bolts (A) by hand. Insert Cam Locks (B) into corresponding holes on Side Panels (2/3). Screw Cam Bolts (A) into threaded holes on Shelf Panel (5). Attach Side Panels (2/3) to Shelf Panel (5) by inserting Cam Bolts (A) and Wood Dowels (C) into corresponding holes until all panels meet.
  • Page 10 Attach Back Panels (14) to back of the unit with Screws (H). Tighten Screws (H) with Phillips screwdriver (not included) Figure 11 Align Screws (K) by hand. Attach Drawer Side Panels (10/11) to Drawer Back Panels (12) using Screws (K). Tighten Screws (K) with Phillips screwdriver (not included).
  • Page 11 Insert drawers into assembled unit. Make sure drawers glide smoothly in and out. Note: There is a lever located on male slide for bottom drawer slide. Push lever to either side in order to detach male slide If drawer does not glide from female slide.
  • Page 12 Move the Sideboard close to the wall. Tie Brackets (M) together with Plastic Straps (L). Warning: Anti-tipping hardware must be used for this product to avoid tipping and injury. Figure 15 Now your Kismet Multi-Finish Cabinet is ready to use! Figure 16 Page | 12...

  • Page 13: Parts Replacement Form

    Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
