HZ105600TX
Parita Bar Cabinet
For assistance with assembly, contact:
Southern Enterprises Inc.
Assembly Instructions
Customer Service: 1-800-633-5096
service@seidal.com
www.seidal.com
PO#:
Page | 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Parita HZ105600TX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SEI Parita HZ105600TX

Summary of Contents for SEI Parita HZ105600TX

  • Page 1 HZ105600TX Parita Bar Cabinet For assistance with assembly, contact: Southern Enterprises Inc. Assembly Instructions Customer Service: 1-800-633-5096 service@seidal.com www.seidal.com PO#: Page | 1...
  • Page 2 Parita Bar Cabinet Parts List Please review all parts and hardware before disposing of any packaging. Before beginning assembly, separate each type of hardware. Carefully study the diagrams below and check that you have all parts indicated. Call Customer Service if missing hardware. Using the incorrect hardware will cause damage. Quantity Quantity Quantity...
  • Page 3 Quantity Quantity Quantity of 2 of 1 of 1 Front Cross Panels Lower Cross Panel Left Door Quantity Quantity Quantity of 1 of 1 of 1 Right Door Drawer Face Panel Left Drawer Side Panel Quantity Quantity Quantity of 1 of 1 of 1 Right Drawer Side Panel...
  • Page 4 Quantity Quantity Quantity of 30 of 30 of 50 Cam Bolts Cam Locks Wood Dowels Dia. 5/16” x1-1/4”L Quantity Quantity Quantity f 20 f 16 f 16 Bolts Spring Washers Flat Washers Dia. 1/4x1-1/4”L Dia. 1/4” Dia. 1/4”x3/4” Quantity Quantity Quantity f 26 of 18...
  • Page 5 Quantity Quantity Quantity Bolts Shelf Pins Bolts Dia. 5/32” x 1-1/8”L Dia. 1/4x1-3/4” L Quantity Quantity Quantity of 9 of 9 of 2 Small Cam Bolts Small Cam Locks Wood Plugs Quantity Quantity of 10 of 2 Cotton Mats Anti-Tipping Hardware Care and Cleaning Instructions: Before using, wipe with a clean, dry cloth.
  • Page 6 Parita Bar Cabinet Assembly Instructions Start with fingers to help align screws. Insert Wood Dowels (C) into holes on Top Panel (1) and both Side Shelf Panels (6). Use Screws (H) to attach Article Wine Racks (26) to Top Panel (1) and both Side Shelf Panels (6).
  • Page 7 Insert Cam Locks (B) into holes on Back Panel (7). Screw Cam Bolts (A) into threaded holes on Upper Shelf Panel (5). Attach Upper Shelf Panel (5) to Back Panel (7) using Cam Bolts (A). Tighten by rotating Cam Locks (B) clockwise with Phillips screwdriver.
  • Page 8 Insert Cam Locks (B) into holes on assembled unit and Cross Panel (11). Screw Cam Bolts (A) into threaded holes on Left Side Panel (2) and Right Side Panel (3). Attach Left and Right Side Panels (2 & 3) to assembled unit and Cross Panel (11) using Cam Bolts (A) and Wood Dowels (C).
  • Page 9 Attach Upper Back Panel (13) to assembled unit with Screws (I). Tighten screws with Phillips screwdriver. Figure 7 Turn assembled unit right-side up. Insert Cam Locks (B) Wood Dowels (C) into holes on assembled unit. Screw Cam Bolts (A) into threaded holes on Top Panel (1).
  • Page 10 Use Bolts (D), Flat Washers (F), Spring Washers (E) and Wood Dowels (C) to connect Front Cross Panels (16) and Lower Cross Panel (17) to Side Frames (14/15). Tighten bolt using Allen Wrench (G). Figure 9 Turn the assembled unit from Figure 8 upsidedown.
  • Page 11 Insert Shelf Pins (T) into holes on middle panels. Insert adjustable Glass Shelf (27) onto pins. Make sure shelf pins stably hold adjustable glass shelf. Figure 11 Start with fingers to help align screws. Attach Hinges (J) to Side Panels (2/3) and Doors (18/19) with Screws (K).
  • Page 12 Attach Drawer Cross Panel (24) to Drawer Front Panel (20) with Small Cam Bolt (V) and Small Cam Lock (W). Attach Drawer Side Panels (21/22) to Drawer Back Panel (23) using Screws (H). Tighten screws with Phillips screwdriver. Insert Drawer Bottom Panel (25) into grooves of Panels (21/22/23).
  • Page 13 Start with finger to help align screws. Attach Brackets (Z) to Back Panel using Screws (Z). Tighten screws with Phillips screwdriver. Mark two desired locations on wall, same distance as Brackets (Z) on back of unit. Drill two 3/16" holes on wall. Insert Plastic Anchors (Z) into holes on wall.

  • Page 14: Parts Replacement Form

    Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
