HZ103900TX
Dunston Bar Cabinet
For assistance with assembly, contact:
Southern Enterprises Inc.
Assembly Instructions
Customer Service: 1-800-633-5096
service@seidal.com
www.seidal.com
PO#:
Page | 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Dunston HZ103900TX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SEI Dunston HZ103900TX

Summary of Contents for SEI Dunston HZ103900TX

  • Page 1 HZ103900TX Dunston Bar Cabinet For assistance with assembly, contact: Southern Enterprises Inc. Assembly Instructions Customer Service: 1-800-633-5096 service@seidal.com www.seidal.com PO#: Page | 1...
  • Page 2 Dunston Bar Cabinet Parts List Please review all parts and hardware before disposing of any packaging. Before beginning assembly, separate each type of hardware. Carefully study the diagrams below and check that you have all parts indicated. Call Customer Service if missing hardware. Using the incorrect hardware will cause damage.
  • Page 3 Quantity Quantity Quantity of 1 of 1 of 1 Left Side Frame Right Side Frame Drawer Face Panel Quantity Quantity Quantity of 1 of 1 of 1 Left Drawer Side Panel Right Drawer Side Panel Drawer Back Panel Quantity Quantity Quantity of 1 of 1...
  • Page 4 Quantity Quantity Quantity of 37 of 37 of 22 Cam Bolts Cam Locks Cotton Mats Quantity Quantity Quantity of 9 of 9 of 50 Small Cam Bolts Small Cam Locks Wood Dowels Dia. 5/16” x1-1/4”L Quantity Quantity Quantity of 2 of 1 of 2 Door Handles...
  • Page 5 Quantity Quantity Quantity of 4 of 24 of 4 Hinges Screws Shelf Pins Dia. 1/8” x 5/8”L Quantity Quantity Quantity of 1 of 2 of 1 Allen Wrench Tilt Prevent Hardware Cam Tool Care and Cleaning Instructions: Before using, wipe with a clean, dry cloth. For replacement parts or questions, please call Periodically apply furniture wax to renew the Customer Service at 1-800-633-5096.
  • Page 6 Dunston Bar Cabinet Assembly Instructions Start screwing with fingers to help align screw. Use Screws (K) and Wood Dowels (F) to attach Article Wine Racks (9) to Top Panel (1) and both Shelf Panels (8). Tighten screws with Phillips screwdriver. Figure 1 Start screwing with finger to help align cam bolts.
  • Page 7 Insert Cam Locks (B) into holes on Upper Back Panel (5). Screw Cam Bolts (A) into threaded holes on Lower Shelf Panel (6). Attach Upper Back Panel (5) to Lower Shelf Panel (6) using Cam Bolts (A). Tighten by rotating Cam Locks (B) clockwise with Phillips screwdriver.
  • Page 8 Start with finger to help align Cam Bolts. Insert Small Cam Locks (E) into pre-drilled holes on Side Small Middle Panel (10). Screw Small Cam Bolts (D) into pre-drilled holes on Lower Shelf Panel (6). Attach assembled unit & Side Small Middle Panel (10) &...
  • Page 9 Insert Cam Locks (B) into holes on assembled unit from Figure 5. Screw Cam Bolts (A) into threaded holes on Top Panel (1). Attach Top Panel (1) to assembled unit using Cam Bolts (A) and Wood Dowels (F). Tighten by rotating Cam Locks (B) clockwise with Phillips screwdriver or Cam Tool (X).
  • Page 10 Insert Cam Locks (B) into holes on Drawer Crossbar (13). Screw Cam Bolts (A) into threaded holes on Left Side Panel (2) and Right Side Panel (3). Attach Left Side Panel (2) and Right Side Panel (3) to Drawer Crossbar (13) using Cam Bolts (A) and Wood Dowels (F).
  • Page 11 Attach Left Door (24) and Right Door (25) onto assembled unit using Hinges (S) and Screws (T). Attach Magnet (P) to assembled unit using Screw (L). Attach Magnet Plate (Q) to inside of door panels using Screws (R). Tighten Screws (T) with a Phillips screwdriver.
  • Page 12 Insert Cam Lock (E) into hole on Drawer Brace Panel (22). Screw Cam Bolt (D) into threaded hole on Drawer Face Panel (18) and attach to Drawer Brace Panel (22). Tighten by rotating Cam Locks (B) clockwise with Phillips screwdriver. Attach Drawer Side Panels (19/20) to Drawer Back Panel (21) using Screws (K).
  • Page 13 Attach Brackets (W) to Back Panel using Screws (W). Tighten Screws (W) using a Philips screwdriver. Mark two desired locations on wall, same distance as Brackets (W) on back of unit. Drill two 3/16" holes on wall. Insert Plastic Anchors (W) into holes on wall. (Use hammer to help.) Attach Brackets (W) to wall using Screws (W).

  • Page 14: Parts Replacement Form

    Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
