- Page 1 HZ032500TX QUINCY 6 DRAWER STORAGE For assistance with assembly contact: Assembly Instructions Southern Enterprises Inc. Customer Service 1-800-633-5096 service@seidal.com www.seidal.com PO#13881...
- Page 2 HZ032500TX QUINCY 6 DRAWER STORAGE Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw. Carefully study the screw diagrams below.
- Page 3 HZ032500TX QUINCY 6 DRAWER STORAGE Assembly Instructions Step 1: Put all parts on a soft surface to prevent scratches. Not fully tighten the bolt until the last steps Attach top frame (A) and divider frame (D) by using bolt (2) and allen key.
- Page 4 Step 3: Attach the assembled frame (C/E) from step 2 above to frame (C) by bolt (2) and allen key as show. Step 4: Attach side frame (B) into the side of the assembled frame of step 3 by using bolt (2) and allen key as show.
- Page 5 Step 5: Attach side frame (B) into the other side of the assembled frame of step 4 by using bolt (2) and allen key as show. Fully tighten all the bolt Step 6: Unfold the woven basket and insert the bottom (H) into the basket (F/G) as show.
- Page 6 Step 7: Attach the bracket (6) into the top edge by using screws (4) as show Step 8: Drill the wall and insert the wall anchor (8) into the wall. Attach the bracket (6) into the wall anchor by using screws (5) as show Insert the plastic string (7) into the 2 bracket (6)
- Page 7 Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
