- Page 1 HZ487400TX Javu Storage Tower For assistance with assembly contact: Assembly Instructions Southern Enterprises Inc. Customer Service 1-800-633-5096 service@seidal.com www.seifurniturestore.com Page 1...
-
Page 2: Parts List
Javu Storage Tower Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or a blanket. Check that you have all parts indicated. Call customer service if any hardware is missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures. - Page 3 Plastic Strap For replacement parts or questions, please Care and cleaning instructions: Before use, wipe with a clean, dry cloth. Call SEI customer service at 1-800-633-5096 Avoid rubbing or scratching the surface with rough or abrasive objects. Assembly Tool Required No.2 Phillips Screwdriver (Not Included)
- Page 4 Javu Storage Tower Assembly Instructions Attach Right Side Frame (C) to Back Frame (A). Insert 4pcs Long Bolt (1) through holes on Back Frame (A) to attach Right Side Frame (C) to Back Frame (A), tighten by using Allen Wrench (4).
- Page 5 Slowly push Metal Tube(D) to both Side Frame (B & C) by hands Insert 2pc Short Bolt (2) through holes on Metal Tube (D) to attach Metal Tube(D) to both Side Frame (B & C) by Allen Wrench (4). Figure 3 Slowly push the Wood Shelf Panel (F) into the both Side Frame(B &...
- Page 6 Slowly push Metal Tube(D) to both Side Frame (B & C) by hands Insert 2pc Short Bolt (2) through holes on Metal Tube (D) to attach Metal Tube(D) to both Side Frame (B & C) by Allen Wrench (4). Figure 5 Slowly push the Wood Shelf Panel (F) to the both side Frame (B &...
- Page 7 Slowly push Metal Tube(D) to both Side Frame (B & C) by hands Insert 2pc Short Bolt (2) through holes on Metal Tube (D) to attach Metal Tube(D) to both Side Frame (B & C) by Allen Wrench (4). Figure 7 Slowly push the Wood Shelf Panel (F) onto the both Side Frame(B &...
- Page 8 Slowly push Metal Shelf Frame(E) onto both Side Frame (B & C) by hands Insert 4pc Short Bolt (2) through holes on Metal Shelf Frame(E) to attach Metal Shelf Frame(E) to both Side Frame (B & C) by Allen Wrench Figure 9 Slowly push Metal Shelf Frame(E) to both Side Frame (B &...
- Page 9 Slowly push Metal Shelf Frame(E) to both Side Frame (B & C) by hands Insert 4pcs Short Bolt (2) through holes on Metal Shelf Frame(E) to attach Metal Shelf Frame(E) to both Side Frame (B & C) by Allen Wrench Figure 11 Please slide one side of Basket Bottom Panel (J) all the way down...
- Page 10 Please slide one side of Basket Bottom Panel (J) all the way down into the bottom of Wicker Basket (H) by hand. Figure 14 Then slowly push the other side of Basket Bottom Panel (J) into the bottom of Wicker Basket (H) by hand.
- Page 11 Find a desired location. Mark 2 locations for screws on wall One screw (for each unit) must be attached directly into a wall stud. Wall anchor is not needed when mounting to wall stud. Drill one of the marking 3/16" hole (for each unit).
- Page 12 Move this item close to the fastened wall brackets and tie in brackets and side frame with Plastic Straps (7) as shown in diagram. Check to make sure the strap is securely laced and locked to the brackets. Figure 20 Now your Javu Storage Tower is ready to use Figure 21...
-
Page 13: Parts Replacement Form
Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
