HZ031200TX
DOMINICK ANYWHERE
For assistance with assembly contact:
Southern Enterprises Inc.
STORAGE CABINET
Customer Service 1-800-633-5096
service@seidal.com
www.seifurniturestore.com
Assembly Instructions
PO:13877
Top supports up to 40 lb.
Each shelf supports up to 20 lb.
HZ031200TX
Page | 1
Advertisement
Related Manuals for SEI HZ031200TX
Summary of Contents for SEI HZ031200TX
- Page 1 HZ031200TX DOMINICK ANYWHERE For assistance with assembly contact: Southern Enterprises Inc. STORAGE CABINET Customer Service 1-800-633-5096 service@seidal.com www.seifurniturestore.com Assembly Instructions PO:13877 Top supports up to 40 lb. Each shelf supports up to 20 lb. HZ031200TX Page | 1...
- Page 2 For replacement parts or questions, please Before using, wipe with a clean, dry cloth. Call Customer Service at 1-800-633-5096. Avoid rubbing or scratching the surface with rough or abrasive objects. Assembly Tool Required: No.2 Phillips Screwdriver HZ031200TX Page | 2 Dominick Anywhere Storage Cabinet...
- Page 3 Step 1: Note: Unit assembly should begin with parts turned upside down for Step Attach Left Panel (2), Right Panel (3) and Back Support (4) to Top Panel (1) using Bolts (A) and Flat Washers (B). Figure 1 Step 2: Insert Black Back Glass Panels (5) along grooves of Left Panel (2), Right Panel (3) and Back Support...
- Page 4 Step 3: Attach Bottom Frame (6) to Left Panel (2) and Right Panel (3) using Bolts (A) and Flat Washers (B). Attach Back support (4) with Bolts (C) and Flat Washers (B) as shown. Figure 3 Step 4: Turn the assembled unit upright. Attach Glass Pads (F) to the brackets on Left Panel (2), Right Panel (3), and Bottom Frame (6).
- Page 5 Step 5: Attach Pads (D) and Pulleys (E) to the bottom of Glass Doors. Figure 5 Step 6: Insert Glass Doors (9) into grooves of Top Panel (1) and Bottom Frame (6). Note: In order to insert doors into grooves, insert top of door first, then insert bottom of door into bottom groove.
-
Page 6: Parts Replacement Form
Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
