HZ1020R0TX –WALNUT/
HZ1021R0TX-BLACK
FOLD-AWAY BAR
For assistance with assembly contact:
Southern Enterprises, Inc.
Customer Service 1-800-633-5096
Assembly Instructions
service@seidal.com
wwww.seidal.com
Supports up to 100Lb
PDF 文件使用 "pdfFactory Pro" 试用版本创建
www.fineprint.cn
Advertisement
Related Manuals for SEI HZ1021R0TX
Summary of Contents for SEI HZ1021R0TX
- Page 1 HZ1020R0TX –WALNUT/ HZ1021R0TX-BLACK FOLD-AWAY BAR For assistance with assembly contact: Southern Enterprises, Inc. Customer Service 1-800-633-5096 Assembly Instructions service@seidal.com wwww.seidal.com Supports up to 100Lb PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn...
- Page 2 HZ1020R0TX-WALNUT/HZ1021R0TX-BLACK FOLD-AWAY BAR Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Screws shown actual size.Using a screw that is too long will cause damage.
- Page 3 HZ1020R0TX-WALNUT/HZ1021R0TX-BLACK FOLD-AWAY BAR Hardware List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw.
- Page 4 HZ1020R0TX-WALNUT/HZ1021R0TX-BLACK FOLD-AWAY BAR Assembly Instructions Step 1 Put all parts on a soft surface to prevent scratches. Attached top shelf(F) and bottle shelf(G) with middle panel(I) by using 2 pcs cam bolt(1), cam lock(2), wood dowel(3) and 2 hinges(4) as shown.
- Page 5 HZ1020R0TX-WALNUT/HZ1021R0TX-BLAC HZ1020R0TX-WALNUT/HZ1021R0TX-BLACK FOLD-AWAY BAR Assembly Instructions Step 3 Attach top panel(A) and bottom panel(J) left board(D) right board(E) by using 4 pcs bolt(1), lock(2) wood dowel(3),long bolt(5) and flat washer(6) as shown. Figure 3 Step 4 Attach left door (B) and right...
- Page 6 HZ1020R0TX-WALNUT/HZ1021R0TX-BLACK FOLD-AWAY BAR Assembly Instructions Step 5 Attach top back panel(K),middle back panel(L) and bottom back panel(M) to the hole body by using 26 pcs Phillip screw(8) as shown. Figure 5 Please mount at least 1 screw into a wall stud. Wall anchor is not needed when screwing directly into a wall stud.
- Page 7 HZ1020R0TX-WALNUT/HZ1021R0TX-BLACK FOLD-AWAY BAR Assembly Instructions Step 8 Attach 2 pcs knobs(11) to left door (B) and right door(C) by using 2 pcs bolt (12),then connect to the wall by using 2 pcs Wall Anchor(9),wall screw(10) and Flat Washer(13) as shown.
-
