Access Point Mode - TP-Link TL-WR841HP Quick Installation Manual

Chapter 2
Note: If the login page does not appear, please refer to the FAQ section.
3 ) After successful login, click
Bridge and follow the step-by-step instructions to complete the initial
configuration.
6. Relocate: Place the router between your host router and the Wi-Fi dead zone. The
location you choose must be within the range of your existing host network.
Host Router
7. Enjoy! The extended network shares the same SSID (Network Name) and password
as your host network.
2. 2. 4.

Access Point Mode

This mode transforms your existing wired network to a wireless one.
Internet Ethernet1 Ethernet2 Ethernet3
Ethernet1 Ethernet2
Wired Host Router
1. Connect the router to your wired host router's Ethernet port via an Ethernet cable as
shown above and turn on the router.
2. Connect a computer to the router via an Ethernet cable or wirelessly by using the
SSID (network name) and password printed on the bottom label of the router.
Next
Host Network
High Power Router
Ethernet4
Ethernet3 Ethernet4
High Power Router
to start the Quick Setup. Select
Extended Network
Connect to the Internet
Repeater/
Client
Client
12
