Chapter 4
• Name (SSID)
• Mode - The current wireless working mode.
• Channel - The current wireless channel.
• Channel Width
• MAC Address
• WDS Status
• WAN - This field displays the current settings of the WAN, and you can configure them
on the Network > WAN
• MAC Address
• IP Address - The current WAN (Internet) IP Address. This field will be blank
or 0.0.0.0 if the IP Address is assigned dynamically and there is no internet
connection.
• Subnet Mask
• Default Gateway
Dynamic IP as the internet connection type, click
obtain new IP parameters dynamically from the ISP or release them.
• DNS Server - The IP addresses of DNS (Domain Name System) server.
• System Up Time - The length of the time since the router was last powered on or
reset.
Click Refresh to get the latest status and settings of the router.
4. 2.

Operation Mode

1. Visit http://tplinkwifi.net, and log in with the username and password you set for the
router.
2. Go to Operation Mode.
3. Select Wireless Router
- The wireless network name of the router.
- The current wireless channel width.
- The physical address of the router.
- The status of WDS connection.
page.
- The physical address of the WAN port.
- The subnet mask associated with the WAN IP Address.
- The Gateway currently used is shown here. When you use
and click Save.
Configure the Router as a Standard Wireless Router
Renew or Release here to
18
