COLOR
WB MODE
AUTO
Auto Tracking White Balance Control mode compensates for color temperature changes
between 2400K
AUTO-EX
Auto White Balance Control mode compensates for color temperature changes
lower than 2000K
PRESET
Preset fixes the white balance based on the current lighting automatically.
MANUAL
Users can control the white balance manually by changing RED GAIN and BLUE
GAIN (see below).
C-TEMP: Select the color temperature for the white balance setup. If enabled,
the Red and Blue Gain settings will be set automatically according to the
C-TEMP selected. Select from 3000K, 5000K, or 8000K. The default value is 5000K.
RED GAIN: 0 ~ 20. Adjusts the amount of red in the image. The default value is 10.
BLUE GAIN: 0 ~ 20. Adjust the amount of blue in the image. The default value is 10.
COLOR GAIN
Set the color gain from 0~20. The default value is 7.
20
o o
and 11000K .
o
and higher than 15000K
o
.
