INSTALLATION-CONNECTING CABLES*
Use the diagram below to connect the camera to external devices:
1
Power
6. Alarm Input: Connect a sensor/alarm input device to the camera's alarm in+ and - cables.
1# DOUT +
ORANGE
1# DOUT -
RED
2# DOUT +
YELLOW
2# DOUT -
BLUE
7. RS485 Connectors: Connect the camera to a controller or the DVR using RS485.
5
AHD 4CH
4
AHD 3CH
3
AHD 2CH
2
AHD 1CH
3# DOUT +
GREEN
3# DOUT -
GRAY
4# DOUT +
WHITE
4# DOUT -
BLACK
7
RS485
6
ALARM
11
