EXPOSURE
LENS
The camera's lens mode is set by default to AUTO. This allows the camera's iris automatically.
Under the LENS sub-menu, you can adjust the following settings:
- Brightness: Adjust the camera's brightness from 0~20. The higher the number, the brighter the
image will appear.
- Shutter: Set the shutter speed to AUTO, Manual, or FLC (Flicker-less mode).
- If AUTO is selected:
- Select NORMAL for INDOOR applications.
- Select DEBLUR for OUTDOOR applications.
- If MANUAL is selected, set the shutter speed from the options: 1/30,1/60, 1/120 ~ 1/30000.
- Focus Adjustment: When on, the default level is set automatically by
controlling lens focus and based on the installation and environment
circumstances.
