Advantech MIO-5272 User Manual

6th gen intel core u-series i7/i5/i3/celeron, 3.5" mi/o-compact sbc, ddr3l, vga, hdmi, 48-bit lvds, 2 gbe, 2 mini pcie, msata, fanless, mioe
Hide thumbs Also See for MIO-5272:
Table of Contents

Advertisement

Quick Links

Manual
ADVANTECH
MIO-5272
The information contained in this document has been carefully researched and is, to the best
of our knowledge, accurate. However, we assume no liability for any product failures or
damages, immediate or consequential, resulting from the use of the information provided
herein. Our products are not intended for use in systems in which failures of product could
result in personal injury. All trademarks mentioned herein are property of their respective
owners. All specifications are subject to change without notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MIO-5272 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Advantech MIO-5272

Summary of Contents for Advantech MIO-5272

  • Page 1 Manual ADVANTECH MIO-5272 The information contained in this document has been carefully researched and is, to the best of our knowledge, accurate. However, we assume no liability for any product failures or damages, immediate or consequential, resulting from the use of the information provided herein.
  • Page 2 User Manual MIO-5272 6th Gen Intel® Core™ U-series (i7/i5/ i3/Celeron®*), 3.5" MI/O-Compact SBC, DDR3L, VGA, HDMI, 48-bit LVDS, 2 GbE, 2 Mini PCIe, mSATA, Fanless, MIOe...
  • Page 3 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
  • Page 4 Because of Advantech’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Advantech product is defec- tive, it will be repaired or replaced at no charge during the warranty period. For out- of-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.

  • Page 5: Declaration Of Conformity

    Discard used batteries according to the manufacturer's instruc- tions. Technical Support and Assistance Visit the Advantech website at http://support.advantech.com where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. Please have the following information ready before you call: –...

  • Page 6: Packing List

    No USB support on MIOe-230 Support with customized BIOS Optional Accessories Part number Description 1960074236N001 Heat spreader 145 x 84 x 16-mm MIO-5272 1935032000 Screw of Heatsink R/S 5.5 2.0 +M M3*20L ST Ni 1700002172 Internal 2 ports USB cable 17CM MIO-5272 User Manual...
  • Page 7 MIO-5272 User Manual...
  • Page 8 Environmental ................5 Block Diagram................... 6 Board layout: dimensions................6 Figure 1.1 MIO-5272 Mechanical Drawing (Top Side) ....6 Figure 1.2 MIO-5272 Mechanical Drawing (Bottom Side) ... 7 Figure 1.3 MIO-5272 Mechanical Drawing (Coastline)....7 Figure 1.4 MIO-5272 Mechanical Drawing (with Heatsink) ..8 Figure 1.5 MIO-5272 Mechanical Drawing (with Heat Spreader) 8...
  • Page 9 Table B.1: System I/O Ports ............78 DMA Channel assignments ..............78 Table B.2: DMA Channel assignments........78 1st MB memory map................78 Table B.3: 1st MB memory map ..........78 Interrupt assignments ................79 Table B.4: Interrupt assignments..........79 MIO-5272 User Manual viii...

  • Page 10: Chapter 1 General Information

    Chapter General Information This chapter gives background information on the MIO-5272. Sections include:  Introduction  Specifications  Block diagram  Board layout and dimensions...

  • Page 11: Introduction

    Introduction MIO-5272 is designed using MI/O Extension form factor (compact series, 146 x 102 mm) and powered by 6th generation of Intel® Core™ U series processors which have low power features but also high performance computing and multimedia capa- bilities. Based on numerous demands from embedded applications, Advantech developed an optimized thermal solution for MIO-5272.
  • Page 12  Supports up to 9 KB jumbo frames (full duplex) * 802.1as/1588 conformance – Port2: i210 Gigabit Ethernet Controller  Flow Control Support compliant with the 802.3X Specification  Compliant with the 1 Gb/s IEEE 802.3 802.3u 802.3ab Specifications MIO-5272 User Manual...

  • Page 13: Os Support

    – TPM2.0*, only support under UEFI mode 1.2.2 OS support MIO-5272 supports Win 10, Win7, WES7 For further information about OS support of MIO-5272, please Advantech website: http://support.advantech.com.tw/ or contact the technical support center. 1.2.3 Mechanical Specifications  Dimensions: 146 x 102 mm (5.7 x 4 inches) ...

  • Page 14: Electrical Specifications

    Storage Temperature: Storage temperature: -40~85°C  Storage Humidity: Relative humidity: 95% @ 60°C It will not be supported in default, please contact to Advantech if this function is needed. Thermal condition need to be considered when setting max frequency. MIO-5272 User Manual...

  • Page 15: Block Diagram

    2 USB 2.0 2 SATA Ports Audio HD Codec In/Out Full-szie miniPCIe 2 RS-232/422/485 Super I/O Full-szie miniPCIe BIOS TPM 2.0 Advantech SMBus/I GPIO Interface iManager Supported by request Board layout: dimensions Figure 1.1 MIO-5272 Mechanical Drawing (Top Side) MIO-5272 User Manual...

  • Page 16: Figure 1.2 Mio-5272 Mechanical Drawing (Bottom Side)

    Figure 1.2 MIO-5272 Mechanical Drawing (Bottom Side) Figure 1.3 MIO-5272 Mechanical Drawing (Coastline) MIO-5272 User Manual...

  • Page 17: Figure 1.4 Mio-5272 Mechanical Drawing (With Heatsink)

    Figure 1.4 MIO-5272 Mechanical Drawing (with Heatsink) Figure 1.5 MIO-5272 Mechanical Drawing (with Heat Spreader) MIO-5272 User Manual...

  • Page 18: Chapter 2 Installation

    Chapter Installation This chapter explains the setup procedures of the MIO-5272 hard- ware, including instructions on setting jumpers and connecting peripherals, switches and indica- tors. Be sure to read all safety pre- cautions before you begin the installation procedure.

  • Page 19: Jumpers & Switches

    Jumpers & Switches The MIO-5272 has a number of jumpers that allow you to configure your system to suit your application. The table below lists the functions of the various jumpers. Table 2.1: Jumpers & Switches Auto Power On Setting...

  • Page 20: Locating Connectors & Block Diagram

    PWR & HDD LED 2 x USB3.0 & 2.0 GbE1 & GbE2 SMBus System FAN * Support by request Figure 2.1 MIO-5272 Connector Locations (Top Side) COM 1 & 2 RS-232/422/485 8 –bit GPIO HD Audio Line-in, Line-out, Mic-in Mini PCIe 1 MIOe 2 x USB2.0...

  • Page 21: Figure 2.3 Mio-5272 Connector Locations (Coastline)

    GbE 1 GbE2 HDMI HDD LED Figure 2.3 MIO-5272 Connector Locations (Coastline) Setting Jumpers You may configure your card to match the needs of your application by setting jump- ers. A jumper is a metal bridge used to close an electric circuit. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them.

  • Page 22: Lcd Power (J2)

    LCD Power (J2) (1-3)* (3-5) (3-4) Table 2.4: LCD Power (J2) Setting Function (1-3)* +3.3V (Default) (3-5) (3-4) +12V 2.4.3 Clear CMOS (SW2) (1-2)* (2-3) Table 2.5: Clear CMOS (SW2) Setting Function (1-2)* Normal (2-3) Clear CMOS MIO-5272 User Manual...
  • Page 23 MIO-5272 User Manual...

  • Page 24: Chapter 3 Ami Bios Setup

    Chapter AMI BIOS Setup...

  • Page 25: Figure 3.1 Setup Program Initial Screen

    AMIBIOS has been integrated into many motherboards for over a decade. With the AMIBIOS Setup program, you can modify BIOS settings and control the various sys- tem features. This chapter describes the basic navigation of the MIO-5272 BIOS setup screens.

  • Page 26: Entering Setup

    Date using the <Arrow> keys. Enter new values through the keyboard. Press the <Tab> key or the <Arrow> keys to move between fields. The date must be entered in MM/DD/YY format. The time must be entered in HH:MM:SS format. MIO-5272 User Manual...

  • Page 27: Advanced Bios Features Setup

    3.2.1 Advanced BIOS Features Setup Select the Advanced tab from the MIO-5272 setup screen to enter the Advanced BIOS Setup screen. You can select any of the items in the left frame of the screen, such as CPU Configuration, to go to the sub menu for that item. You can display an Advanced BIOS Setup option by highlighting it using the <Arrow>...

  • Page 28: Figure 3.4 Pci Subsystem Settings

    ACPI Sleep State Select the highest ACPI sleep state the system will enter when the SUSPEND button is pressed. Lock Legacy Resources Enables or Disables Lock of Legacy Resources. S3 Video Repost Enable or Disable S3 Video Repost. MIO-5272 User Manual...
  • Page 29 Enable/Disable Alert Specification Format. Activate Remote Assistance Process Trigger CIRA boot. USB Provisioning of AMT Enable/Disable of AMT USB Provisioning. PET Progress User can Enable/Disable PET Events progress to receive PET events or not. Watch Dog Enable/Disable WatchDog Timer. MIO-5272 User Manual...
  • Page 30 This page display all information about system ME FW. ME Unconfig on RTC Clear State Disabling this option will cause ME not to unconfigure on RTC clear. ME State Set ME to Soft Temporary Disabled. Firmware Update Configuration Configure Management Engine Technology Parameters. MIO-5272 User Manual...
  • Page 31 Power Saving Mode This item allows users to set board’s power saving mode when off. Deep Sleep delay time Set delay time for Deep Sleep mode. Watch Dog Timer This item allows users to select EC watchdog timer. MIO-5272 User Manual...
  • Page 32 Device. TCG EFI protocol and INT1A interface will not be available. 3.2.1.6 S5 RTC Wake Settings Wake system from S5 Enable or disable System wake on alarm event. Select FixedTime, system will wake on the hr::min::sec specified. MIO-5272 User Manual...
  • Page 33 3.2.1.7 Serial Port Console Redirection Console Redirection This item allows users to enable or disable console redirection for Microsoft Windows Emergency Management Services (EMS). Console Redirection This item allows users to configuration console redirection detail settings. MIO-5272 User Manual...
  • Page 34 Enable/Disable Intel® Speed Shift Technology support. Intel® SpeedStep™ Allows more than two frequency ranges to be supported. Turbo Mode Turbo Mode. CPU C states Enable or disable CPU C states. CState Pre-Wake Disable – to disable the CState Pre-Wake. MIO-5272 User Manual...
  • Page 35 Package C State limit Package C State limit. SW Guard Extension (SGX) Enable/Disable Software Guard Extensions (SGX). 3.2.1.9 Intel TXT Information Intel TXT Information Display Intel TXT information. MIO-5272 User Manual...
  • Page 36 3.2.1.10 Platform Misc Configuration Native PCIE Enable PCI Express Native Support Enable/Disable. Native ASPM PCI Express Native ASPM Enable/Disable. 3.2.1.11 SATA Configuration MIO-5272 User Manual...
  • Page 37 Enable / Disable Serial ATA Port 1 / Port 2 / mSATA Port. SATA Device type Identify the SATA port is connected to Solid State Drive or Hard Disk Drive. 3.2.1.12 Network Stack Configuration Network Stack Enable/Disable UEFI Network Stack. MIO-5272 User Manual...
  • Page 38 Controls the execution of UEFI and Legacy PXE OpROM. Storage Controls the execution of UEFI and Legacy Storage OpROM. Video Controls the execution of UEFI and Legacy Video OpROM. Other PCI devices Determines OpROM execution policy for devices other than Network, Storage, or Video. MIO-5272 User Manual...
  • Page 39 Maximum time the device will take before it properly reports itself to the Host Control- ler. 'Auto' uses default value: for a Root port it is 100 ms, for a Hub port the delay is taken from Hub descriptor. MIO-5272 User Manual...
  • Page 40 3.2.1.15 IT8768E Super I/O Configuration Serial Port 1 Configuration Set Parameters of Serial Port 1 (COMA). Serial Port 2 Configuration Set Parameters of Serial Port 2 (COMB). MIO-5272 User Manual...

  • Page 41: Chipset

    3.2.2 Chipset Select the Chipset tab from the MIO-5272 setup screen to enter the Chipset BIOS Setup screen. You can display a Chipset BIOS Setup option by highlighting it using the <Arrow> keys. All Plug and Play BIOS Setup options are described in this sec- tion.

  • Page 42: Figure 3.6 System Agent (Sa) Configuration

    3.2.2.1 System Agent (SA) Configuration Figure 3.6 System Agent (SA) Configuration VT-d VT-D capability. CRID Support Enable/Disable CRID control for Intel SIPP. Above 4GB MMIO BIOS assignment Enable/Disable above 4GB Memory Mapped IO BIOS assignment. MIO-5272 User Manual...
  • Page 43 Select DVMT 5.0 Pre-Allocated (Fixed) Graphics Memory size used by the Internal Graphics Device. DVMT Total Gfx Mem Select DVMT 5.0 Total Graphic Memory size used by the Internal Graphics Device. PM Support Enable/Disable PM Support. PAVP Enable Enable/Disable PAVP. MIO-5272 User Manual...
  • Page 44 Secondary boot display selection will appear based on your selection. VGA modes will be supported only on primary display. LVDS Panel Type This item allow user to select LVDS panel type. 2nd LVDS Backlight Control Switch Backlight Control for PWM or DC mode. MIO-5272 User Manual...
  • Page 45 Max TOLUD Maximum Value of TOLUD. SA GV System Agent Geyserville. SA GV Low Freq System Agent Geyserville. Set frequency for low point. Energy Performance Gain Enable/disable Energy Performance Gain. Memory Remap Enable/Disable Memory Remap above 4GB. MIO-5272 User Manual...
  • Page 46 3.2.2.5 GT – Power Management Control RC6 Render Standby) Check to enable render standby support. 3.2.2.6 PCH-IO Configuration PCI Express Configuration PCI Express Configuration Settings. MIO-5272 User Manual...
  • Page 47 Enable or Disable PCIE to wake the system from S5. High Precision Timer Enable or Disable High Precision Event Timer. State After S3 Specify what state to go to when power is re-applied after a power failure (G3 state). MIO-5272 User Manual...
  • Page 48 DMI Link ASPM Control Enable/Disable the control of Active State Power Management on SA side of the DMI Link. Peer Memory Write Enable Peer Memory Write Enable/Disable. PCI Express Root Port 1/2/5/9 PCI Express Port 1/2/5/9 Settings. MIO-5272 User Manual...
  • Page 49 Precondition work on USB host controller and root ports for faster enumeration. XHCI Disable Compliance mode Option to disable Compliance Mode. USB Port Disable Override Selectively Enable/Disable the corresponding USB Port from reporting a Device Con- nection to the Controller. MIO-5272 User Manual...
  • Page 50 3.2.2.9 BIOS Security Configuration RTC Lock Enable will lock bytes 38h-3Fh in the lower/upper 128-byte bank of RTC RAM. BIOS Lock Enable or Disable the PCH BIOS Lock Enable feature. 3.2.2.10 HD Audio Configuration MIO-5272 User Manual...
  • Page 51 HD Audio Control Detection of the HD-Audio device. Disabled = HDA will be unconditionally disabled. Enabled = HDA will be unconditionally Enabled. 3.2.2.11 SB Porting Configuration SATA RAID ROM Run the Legacy ROM or UEFI Driver. MIO-5272 User Manual...

  • Page 52: Security

    Security Figure 3.7 Password Configuration Select Security Setup from the MIO-5272 Setup main BIOS setup menu. All Security Setup options, such as password protection and virus protection are described in this section. To access the sub menu for the following items, select the item and press <Enter>:...

  • Page 53: Boot

    Enables or disables boot with initialization of a minimal set of devices required to launch active boot option. Has no effect for BBS boot options. New Boot Option Policy Controls the placement of newly detected UEFI boot options. MIO-5272 User Manual...

  • Page 54: Save & Exit

    Restore Defaults The MIO-5272 automatically configures all setup items to optimal settings when users select this option. Optimal Defaults are designed for maximum system perfor- mance, but may not work best for all computer applications. In particular, do not use the Optimal Defaults if the user's computer is experiencing system configuration problems.
  • Page 55 When users have completed system configuration, select this option to save changes as user defaults without exit BIOS setup menu. Restore User Defaults The users can select this option to restore user defaults. Boot Override This item allows users to choose boot device. MIO-5272 User Manual...
  • Page 56 Chapter MIOe Installation...

  • Page 57: Quick Installation Guide

    There is a Heatsink / Cooler in the white box inside the package. Carefully remove the release paper from the thermal pad before installation. Remove release paper There are eight screws, six studs and two nuts inside the white box, please install the heatsink into place as per illustration below: MIO-5272 User Manual...

  • Page 58: Pin Assignments

    Appendix Pin Assignments This appendix contains informa- tion of a detailed or specialized nature. Sections include:  Jumper and Connector Tables...

  • Page 59: Jumper, Switch List And Setting

    PIN HEADER 3x2P 2.0mm 180D(M) SMD 21N22050 Setting Function (1-3)* +3.3V (default) (3-5) (3-4) +12V Clear CMOS Part Number 1600000071 Footprint SW_3P_CJS-1201TA1 Description DIP SW CJS-1201TA1 SMD 3P SPDT P=6.0mm W=2.5mm Function 2->1 Normal 2->3 Clear CMOS (RTC RST#) MIO-5272 User Manual...
  • Page 60 ATX PWRCONN 2x2P 4.2mm 90D(M) DIP 740-77-04TS50 Pin Name +12V +12V DC JACK (Support by request) Part Number 1652005278 Footprint PJ_2P_2DC-G213B200 Description Pin Name +12V Battery Part Number 1655005427-01 Footprint WF_2P_49_53398-0271 Description WAFER BOX 2P 1.25mm 180D(M) DIP 53047-0210 Pin Name MIO-5272 User Manual...
  • Page 61 Footprint DDR3_204P_AS0A626-N2S6-7H Power Switch Part Number 1655302020 Footprint WF_2P_79_BOX_R1_D Description WAFER BOX 2P 2.0mm 180D(M) DIP A2001WV2-2P Pin Name PSIN Reset Part Number 1655302020 Footprint WF_2P_79_BOX_R1_D Description WAFER BOX 2P 2.0mm 180D(M) DIP A2001WV2-2P Pin Name RESET# MIO-5272 User Manual...
  • Page 62 Footprint HD_5x2P_79_23N685B-10M10 Description BOX HEADER 5x2P 2.00mm 180D(M) SMD 23N685B-10M10 Pin Name GPIO4 GPIO0 GPIO5 GPIO1 GPIO6 GPIO2 GPIO7 GPIO3 CN11 SATA Part Number 1654007578 Footprint SATA_7P_WATF-07DBN6SB1U Description Serial ATA 7P 1.27mm 180D(M) SMD WATF-07DBN6SB1U Pin Name MIO-5272 User Manual...
  • Page 63 CN12 SATA Part Number 1654011616-01 Footprint SATA_7P_WATF-07DBN6SB1U Description Serial ATA 7P 1.27mm 180D(M) SMD WATF-07DBLSB1UW Pin Name CN13 SATA Power Part Number 1655001154 Footprint WF_4P_98_BOX_R1_D Description WAFER BOX 4P 2.50mm 180D(M) DIP 24W1170-04S10-01 Pin Name +12V MIO-5272 User Manual...
  • Page 64 MINI PCI E 52P 6.8mm 90D SMD AS0B226-S68N7H Pin Name WAKE# +3.3VSB +1.5V CLK_MIN1_z_REQ# +VUIM_PWR UIM_DATA REFCLK- UIM_CLK REFCLK+ UIM_RESET +VUM_VPP W_DISABLE# PERST# PERn0 +3.3VSB PERp0 +1.5V SMB_CLK PETn0 SMB_DATA PETp0 USB D- USB D+ +3.3VSB +3.3VSB MIO-5272 User Manual...
  • Page 65 +1.5V +3.3VSB MIO-5272 User Manual...
  • Page 66 Description MINI PCI E 52P 6.8mm 90D SMD AS0B226-S68N7H Pin Name WAKE# +3.3VSB +1.5V UIM_PWR UIM_DATA REFCLK- UIM_CLK REFCLK+ UIM_RESET UIM_VPP W_DISABLE# PERST# PERn0 +3.3VSB PERp0 +1.5V SMB_CLK PETn0 SMB_DAT PETp0 USB D- USB D+ +3.3VSB +3.3VSB MIO-5272 User Manual...
  • Page 67 +1.5V +3.3VSB MIO-5272 User Manual...
  • Page 68 CN15 Part Number 1654010809-01 Footprint SIM_6P_5210622-SINR03 Description Pin Name UIM_PWR UIM_RESET UIM_CLK UIM_VPP UIM_DATA CN16 External USB2.0+USB3.0 Part Number 1654010199 Footprint USB_13P_UEA1112C-UHS6-4F Description Pin Name SSRX- SSRX+ SSTX- SSTX+ MIO-5272 User Manual...
  • Page 69 CN17 External USB2.0+USB3.0 Part Number 1654010199 Footprint USB_13P_UEA1112C-UHS6-4F Description Pin Name SSRX- SSRX+ SSTX- SSTX+ MIO-5272 User Manual...
  • Page 70 CN18 COM1/COM2 Part Number 1653004793 Footprint HD_10x2P_79_23N685B-20M10 Description BOX HEADER 10x2P 2.0mm 180D(M)SMD 23N685B-20M10B Pin Name DCD1# DSR1# RXD1 RTS1# TXD1 CTS1# DTR1# RI1# DCD2# DSR2# RXD2 RTS2# TXD2 CTS2# DTR2# RI2# Matching Cable: 1701200220 MIO-5272 User Manual...
  • Page 71 CN19 COM3/COM4/RS422/RS485 Part Number 1653004793 Footprint HD_10x2P_79_23N685B-20M10 Description BOX HEADER 10x2P 2.0mm 180D(M)SMD 23N685B-20M10B Pin Name COM3_485-422_TXN-DCD# COM3_z_DSR# COM3_485-422_TXP-RXD COM3_z_RTS# COM3_422__RXP-TXD COM3_z_CTS# COM3_422__RXN-DTR# COM3_z_RI# COM4_485-422_TXN-DCD# COM4_z_DSR# COM4_485-422_TXP-RXD COM4_z_RTS# COM4_422__RXP-TXD COM4_z_CTS# COM4_422__RXN-DTR# COM4_z_RI# MIO-5272 User Manual...
  • Page 72 CN19 COM1/2 RS-232/422/485 Part Number 1653004793 Footprint HD_10x2P_79_23N685B-20M10 Description BOX HEADER 10x2P 2.0mm 180D(M)SMD 23N685B-20M10B Pin Name 422TX<1>-/485D<1>-/DCD<1># DSR<1># 422TX<1>+/485D<1>+/RXD<1> RTS<1># 422RX<1>+/TXD<1> CTS<1># 422RX<1>-/DTR<1># RI<1># 422TX<2>-/485D<2>-/DCD<2># DSR<2># 422TX<2>+/485D<2>+/RXD<2> RTS<2># 422RX<2>+/TXD<2> CTS<2># 422RX<2>-/DTR<2># RI<2># MIO-5272 User Manual...
  • Page 73 CN21 Gigabit Ethernet 1 & 2 Part Number 1652003274 Footprint RJ45_28P_RTB-19GB9J1A Description PHONE JACK RJ45 28P DIP RTB-19GB9J1A Pin Name TX+(10/100),BI_DA+(GHz) TX-(10/100),BI_DA-(GHz) RX+(10/100),BI_DB+(GHz) BI_DC+(GHz) BI_DC-(GHz) RX-(10/100),BI_DB-(GHz) BI_DD+(GHz) BI_DD-(GHz) MIO-5272 User Manual...
  • Page 74 BOX HEADER 5x2P 2.00mm 180D(M) SMD 23N685B-10M10 Pin Name LOUTR LINR LOUTL LINL MIC1R MIC1L CN24 External USB3.0*2 Part Number 1654011725-01 Footprint USB_9x2P_WDU3R-18F3B4PBUW3 Description Double USB 3.0 CONN. 18P 90D(F) DIP WDU3R-18F6B4 Pin Name SSRX- SSRX+ SSTX- SSTX+ SSRX- SSRX+ SSTX- SSTX+ MIO-5272 User Manual...
  • Page 75 CN25 External USB2.0*2 Part Number 1654010634-01 Footprint USB_8P_ABA-USB-014-K01 Description USB Conn. 8P 2.5mm 90D(M) DIP ABA-USB-014-K01 Pin Name MIO-5272 User Manual...
  • Page 76 Footprint HD_5x2P_79_N10 Description PIN HEADER 2x5P 2.0mm 180D(M) SMD 21N22050 Pin Name A_D- B_D- A_D+ B_D+ CN27 Part Number 1654011261-01 Footprint DBVGA-VF5MS Description D-sub 15P 90D(F) DIP G/F HDB5-15F1-KNR0-G7 Pin Name GREEN BLUE DDAT HSYNC VSYNC DCLK MIO-5272 User Manual...
  • Page 77 CN24 MIOe Part Number 1654006235 Footprint BB_40x2P_32_1625x285_2HOLD Description B/B Conn. 40x2P 0.8mm 180D(F) SMD QSE-040-01-L-D Pin Name PCIE_RX0+ PCIE_TX0+ PCIE_RX0- PCIE_TX0- PCIE_CLK+ LOUTL PCIE_CLK- LOUTR AGND SMB_STB_CLK SMB_STB_DAT PCIE_WAKE# RESET# PowerOn CLK33M MIO-5272 User Manual...
  • Page 78 LPC_AD0 DDP_HPD LPC_AD1 LPC_AD2 DDP_AUX+ LPC_AD3 DDP_AUX- LPC_SERIRQ DDP_D0+ LPC_FRAME# DDP_D0- USB0_D+ DDP_D1+ USB0_D- DDP_D1- USB1_D+ DDP_D2+ USB1_D- DDP_D2- USB2_D+ DDP_D3+ USB2_D- DDP_D3- USB_OC# +12VSB +12VSB +5VSB +5VSB +5VSB +5VSB MIO-5272 User Manual...
  • Page 79 CN29 SMBus Part Number 1655904020 Footprint FPC4V-125M Description WAFER 4P 1.25mm 180D(M) SMD 85205-04001 Pin Name SMB_DAT SMB_CLK MIO-5272 User Manual...
  • Page 80 CN26 48 bits LVDS Panel Part Number 1653920200 Footprint SPH20X2 Description B/B Conn. 40P 1.25mm 90D SMD DF13-40DP-1.25V(91) Pin Name +V_LCD +V_LCD +V_LCD +V_LCD LVDS0_D0- LVDS1_D0- LVDS0_D0+ LVDS1_D0+ LVDS0_D1- LVDS1_D1- LVDS0_D1+ LVDS1_D1+ LVDS0_D2- LVDS1_D2- LVDS0_D2+ LVDS1_D2+ LVDS0_CLK- MIO-5272 User Manual...
  • Page 81 LVDS1_CLK- LVDS0_CLK+ LVDS1_CLK+ LVDS0_D3- LVDS1_D3- LVDS0_D3+ LVDS1_D3+ MIO-5272 User Manual...
  • Page 82 Pin Name TMDS Data2+ TMDS Data2 Shield TMDS Data2– TMDS Data1+ TMDS Data1 Shield TMDS Data1– TMDS Data0+ TMDS Data0 Shield TMDS Data0– TMDS Clock+ TMDS Clock Shield TMDS Clock– Reserved Reserved +5V Power Hot Plug Detect MIO-5272 User Manual...
  • Page 83 FAN1 System FAN Part Number 1655003010 Footprint WHP3VA Description Pin Name +V12 MIO-5272 User Manual...
  • Page 84 MIO-5272 User Manual...
  • Page 85 MIO-5272 User Manual...

  • Page 86: System Assignments

    Appendix System Assignments This appendix contains informa- tion of a detailed nature. Sections include:  System I/O Ports  DMA Channel Assignments  1st MB Memory Map  Interrupt Assignments...

  • Page 87: System I/O Ports

    Table B.3: 1st MB memory map Addr. Range (Hex) Device E0000h - FFFFFh System board D0000h - DFFFFh PCI Bus C0000h - CFFFFh System board A0000h - BFFFFh PCI Bus A0000h - BFFFFh Intel® HD Graphic 00000h - 9FFFFh System board MIO-5272 User Manual...

  • Page 88: Interrupt Assignments

    Communications Port (COM2) IRQ4 Communications Port (COM1) IRQ5 EC Watch DOG IRQ6 Available IRQ7 Available IRQ8 System CMOS/real time clock IRQ9 Microsoft ACPI-Compliant System IRQ10 Available IRQ11 SATA controller IRQ12 Available IRQ13 Numeric data processor IRQ14 Reserved IRQ15 Reserved MIO-5272 User Manual...
