MIO-5270 MI/O Extension SBC, AMD® G- Series, DDR3, HDMI, 48-bit
LVDS, VGA, 2 GbE, CFast, iManager, MIOe
Startup Manual
Packing List
Before you begin installing your board, please make sure
that the following items have been shipped:
• 1 x MIO-5270 SBC
• 1 x SATA Cable 30cm
• 1 x SATA Power Cable 35cm
• 1 x Audio Cable 20cm
• 2 x COM Cable 22cm
• 1 x COM RS-422/485 Cable 25cm
• 1 x Heatsink (25mm) for T40E/T40R
• 1 x Cooler (25mm) for T56N
• Startup Manual
• CD-ROM (Manual, Driver, Utility)
• 1 x Mini Jumper(10pcs package)
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note1:
For detailed contents of MIO-5270, please refer
to information on the enclosed CD-ROM (in PDF
format).
Note1:
Acrobat Reader is required to view any PDF file.
Acrobat Reader can be downloaded at: www.
adobe.com/Products/acrobat/readstep2.html
(Acrobat is a trademark of Adobe)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://service.advantech.com.tw/support/
This manual is for the MIO-5270.
Part No. 2006527000
Printed in China
(P/N 1700006291)
(P/N 1700018785)
(P/N 1700019584)
(P/N 1701200220)
(P/N 1700019435)
(P/N: 1960053507N001)
(P/N 1960053508N001)
(P/N 9689000002)
1st Edition
September 2011
Specifications
General
• CPU: AMD G-Series
T56N (Dual Core 1.65GHz): MIO-5270D-S6A1E
T40E (Dual Core 1.0GHz): MIO-5270D-S0A1E
T40R (Single Core 1.0GHz): MIO-5270S-S0A1E
• System Memory: 1 x 204-pin SODIMM socket DDR3 up to 4GB
T56N: DDR3 1333 MHz
T40E/T40R: DDR3 1066 MHz
• 2nd Cache Memory:
T56N: 1MB
T40E/T40R: 512KB
• System Chipsets: AMD G-series + A50M FCH
• BIOS: AMI EFI 32-Mbit
• Watchdog Timer: 255 levels timer interval, program-
mable by software. Multi level WDT (set by iManager)
• Expansion Interface: PCIe Mini Card, CFast, MIOe
• Battery: Lithium 3 V / 210 mAH
• Audio: Support High Definition Audio (HD), line-in, line-
out, Mic-in
Display
• Controller: AMD G-series T56N/T40E/T40R
• Resolution:
-- VGA:
T56N: 2560 x 1600
T40E/T40R: 1920 x 1200
-- LVDS:
LVDS suppots single channel 24-bit/dual channels 48-bit
T56N: 2560 x 1600 @60Hz
T40E/T40R: 1920 x 1200 @60Hz
(Pixel clock rate 80MHz)
-- HDMI:
Supports 1920 x 1080p @60Hz, 36bpp
Supports HDMI 1.3, using TMDS data encoding
• Dual Independent Display:
VGA+LVDS, VGA+HDMI, HDMI+LVDS

Ethernet Interface

• Speed: GbE 10/100/1000 Mbps
• Chipset: Realtek RTL8111E- VB-GR (GbE1, GbE2)
• Ethernet Interface: Fully compliant with IEEE 802.3,
IEEE 802.3u, IEEE 802.3ab
• Connector: RJ45 x2
I/O
• Internal I/O Interface: 2 x SATAII, 3 x RS-232, 1 x
RS232/422/485, 2 x USB 2.0, GPIO, SMBus
• Rear I/O: 4 x USB 2.0, HDMI, VGA, 2 x RJ45 Ethernet,
DC Power in connector
• DC Power in connector:
T56N: 2 x 2 pin power connector
T40E/T40R: DC Jack
• GPIO: 8-bit general purpose input/output
MIO-5270 Startup Manual 1

Advertisement

loading

Summary of Contents for Advantech MIO-5270

  • Page 1: Ethernet Interface

    MIO-5270 MI/O Extension SBC, AMD® G- Series, DDR3, HDMI, 48-bit LVDS, VGA, 2 GbE, CFast, iManager, MIOe Startup Manual Packing List Specifications General Before you begin installing your board, please make sure that the following items have been shipped: • CPU: AMD G-Series •...
