Matrox 6150 Encoder User Manual page 42

Maevex 5150 Encoder
Product type
Video input connector
Video output connectors
Audio input connector
Audio output connector
Network connector
RS232 connector
Video stream output
Audio stream support
Streaming protocols
Command protocols
Supported resolutions (input)
Supported resolutions (output)
Additional supported HDMI
†
resolutions
Maximum unicast connections
Power requirements
Power connector
Power consumption
Dimensions
Certifications
* All supported resolutions have a vertical refresh rate of 60 Hz.
† When using a display resolution equal to or higher than 1280×720p60, we recommend you use certified high-speed HDMI
cables.
‡ When pass through is enabled, only the resolutions supported by your monitor may be available.
§ Interlaced resolutions are only supported at input. When using interlaced resolutions, the capture rate selection is disabled
and your encoder automatically captures all frames.
¶ With a resolution of 1080p at 15Mb/s.
** With a stream of 1080p60 at 25Mb/s.
42 Matrox Maevex Series – User Guide
1× DE9 (also known as DB9) – female
MPEG4-GENERIC (firmware version newer than 1.03.03),
MPEG4-LATM (up to firmware version 1.03.03)
1920 × 1200, 1920 × 1080, 1680 × 1050, 1600 × 1200,
1600 × 900, 1440 × 900, 1400 × 1050, 1360 × 768,
*†‡
1280 × 1024, 1280 × 960, 1280 × 720, 1024 × 768,
800 × 600, 720 × 576, 720 × 480, and 640 × 480
1920 × 1200, 1920 × 1080, 1680 × 1050, 1600 × 1200,
1600 × 900, 1440 × 900, 1400 × 1050, 1366 × 768,
1360 × 768,1280 × 1024, 1280 × 960, 1280 × 768,
1280 × 720, 1024 × 768,852 × 480, 848 × 480,
800 × 600, 720 × 576, 720 × 480, and 640 × 480
1080p50, 1080p30, 1080i60/50
¶
5V DC, maximum 5 A (5 A fuse for overcurrent protection)
21.59 cm × 2.59 cm × 10.16 cm /
Class B: ACMA, CE, FCC, ICES, VCCI, Korea
Maevex 5150 encoder
Standalone appliance
1× HDMI
1× HD-15 (VGA) + 1× HDMI
1× mini-stereo jack
1× mini-stereo jack
1× RJ45
MPEG-4 Part 10 / AVC (H.264)
RTP, RTSP, RTCP, UDP
TCP/IP, UPnP, HTTPS
720p50, and 576p50
8
DIN 4 female (4-pin)
**
Maximum: 9 W
Minimum: 6 W
8.50 in × 1.02 in × 4.00 in
§
,
