Product information

Specifications
Maevex 6150 Encoder
Product type
Form factor
System memory
Video input connectors
Video output connectors
Audio input connector (analog)
Audio output connector
(headphone)
Microphone input connector
RS232 connector
Networking interface
USB ports
Color sampling and conversion
Audio encoding (max. bitrate)
Video encoding
Streaming protocols
Command protocols
Supported resolutions
(HDMI video input and output)
38 Matrox Maevex Series – User Guide
4× HDMI Type A (with 16-bit stereo L-PCM audio)
4× HDMI Type A (with 16-bit stereo L-PCM audio),
and 1× DisplayPort (for console display)
1× DE9 (also known as DB9) – male
2× 100/1000 Base-T RJ45 Ethernet Port, auto-speed, half/full
duplex, unicast, multicast, and multi-unicast
(1× control and stream, and 1× secondary stream)
AAC-LC (576 kpbs), HEv1 (288 kpbs), HEv2 (144 kpbs)
H.264/MPEG-4 Part 10 (AVC), Up to level 5.2,
Baseline profile (BP), Main profile (MP), High profile (HiP),
High 10 profile (Hi10P), High 4:2:2 profile (Hi422P),
High 4:4:4 predictive profile separate plane (Hi444PP),
4096 × 2160p24/25/30/50
3840 × 2160p24/25/30/50
1920 × 1200p56/60, 1920 × 1080i50/60,
*†
1920 × 1080p30/50/60, 1680 × 1050, 1600 × 1200, 1440 × 900,
1400 × 1050, 1280 × 1024, 1280 × 720p50/60, 1024 × 768,
800 × 600, 720 × 576, 720 × 480, and 640 × 480
Maevex 6150 encoder
Standalone appliance
1 RU, half width
4 GB
4× mini-stereo jacks
1× mini-stereo jack
1× mini-stereo jack
2× USB 2.0 (front),
1× USB 3.0 (back)
4:2:0, 4:0:0 (8-bit and 10-bit)
4:4:4, 4:2:2 (8-bit)
CAVLC 4:4:4 Intra (44)
RTP, RTSP, RTMP, MPEG-2 TS
UPnP, HTTPS
‡ ‡
/60 , 2560 × 1600, 2560 × 1440,
‡ ‡
/60 ,
