Maevex 6100 Encoder
Product type
Form factor
Memory
Input connectors
Networking interface
Color sampling and conversion
Audio encoding
(Maximum bit rate)
Video encoding
Streaming protocols
Command protocols
Supported resolutions
Multi-encode/
Multi-stream/
§
Record
Maximum bit rate
(per stream)
Maximum combined bit rates
(all streams and recordings)
Rate control
Recording
Recording location
Maximum power consumption
Maximum card dimensions
Certifications
40 Matrox Maevex Series – User Guide
4× Mini HDMI Type C (with 16-bit digital L-PCM audio (stereo))
1× 100/1000 Base-T RJ45 Ethernet Port, auto-speed, half/full
AAC-LC (576 kpbs), HEv1 (288 kpbs), HEv2 (144 kpbs)
Baseline profile (BP), Main profile (MP), High profile (HiP),
High 10 profile (Hi10P), High 4:2:2 profile (Hi422P),
High 4:4:4 predictive profile separate plane (Hi444PP),
3840 × 2160p24/25/30/50
*†
1920 × 1080p30/50/60, 1680 × 1050, 1600 × 1200, 1440 × 900,
1400 × 1050, 1280 × 1024, 1280 × 720p50/60, 1024 × 768,
800 × 600, 720 × 576, 720 × 480, and 640 × 480
2× 3840 × 2160 @ 60 Hz, 4× 3840 × 2160 @ 30 Hz,
8× 1920 × 1080 @ 60 Hz, 16× 1280 × 720 @ 60 Hz,
¶
Constrained VBR, Configurable group of pictures (GOP)
Maevex 6100 encoder
PCIe ×8 card (power only)
Full height
4 GB
duplex, unicast, multicast, and multi-unicast
4:2:0, 4:0:0 (8-bit and 10-bit)
4:4:4, 4:2:2 (8-bit)
H.264/MPEG-4 Part 10 (AVC), Up to level 5.2,
CAVLC 4:4:4 Intra (44)
RTP, RTSP, RTMP, MPEG-2 TS
UPnP, HTTPS
4096 × 2160p24/25/30/50
‡
/60
1920 × 1200p56/60, 1920 × 1080i50/60,
or numerous SD IP channels
120 Mbps
800 Mbps
Constant bit rate (CBR), Variable bit rate (VBR),
MP4 file format
NAS device
24.6 W (12 V), 6.1 W (3.3 V)
Total: 30.7 W
22.9 cm × 1.91 cm × 11.1 cm /
9.02 in × 0.75 in × 4.376 in
Class B: ACMA, CE, FCC, ICES, VCCI, Korea
‡ ‡
/60 ,
‡
, 2560 × 1600, 2560 × 1440,
