External power supply

Input AC voltage range
Input frequency
Input connector
Output voltage
Output connector
Maximum power
Environmental
Temperature, operational
Temperature, non-operational
storage and transportation
Humidity, operational (indoor)
Humidity, non-operational storage
and transportation
Atmospheric pressure, operational
Atmospheric pressure,
non-operational and transportation
44 Matrox Maevex Series – User Guide
6150 encoder
100V to 240V AC 100V to 240V AC
50 to 60 Hz
IEC 60320-C13
+12V DC, 5A
DIN 4 male (4-pin) DIN 4 male (4-pin)
with lock
60 W
0 to 45 ºC (32 to 113 ºF)
-40 to 70 ºC (-40 to 158 ºF)
20% to 80% (non-condensing)
5% to 95% (non-condensing)
650hPa (3,580 meters / 11,745 feet)
to 1013hPa (0 meters / 0 feet)
192hPa (12,000 meters / 39,370 feet)
to 1020hPa (-50 meters / -164 feet)
5150 encoder 5150 decoder
100V to 240V AC
50 to 60 Hz
IEC 60320-C8 IEC 60320-C8
+5V DC, 3A
DIN 4 male (4-pin)
with lock
15 W
50 to 60 Hz
+5V DC, 3A
with lock
15 W
