Insert your Matrox card
2
Position your Matrox card over the
a
expansion slot you've chosen.
Push the card in firmly and evenly until
b
it's fully seated in the slot.
Secure the bracket of your Matrox card
c
to the frame of your system.
Your Matrox card is now installed. If you're installing more than one card,
cards", page 19. Before restarting your system, connect your devices (see the "Connection setup"
section for the card you want to connect). After connecting, restart your system and install your
Matrox software.

Installing multiple cards

Your system may support the installation of multiple Maevex cards in your system.
WARNING:
cards, always insert your card as straight as
possible into the slot. Don't rock the card
from side to side. If you meet resistance,
don't force the card into the slot.
To avoid damaging your
see "Installing multiple
Matrox Maevex Series – User Guide 19
