Supported resolutions
(DisplayPort video output for
console display)
Multi-encode/
Multi-stream/
§
Record
Maximum bit rate
(per video stream)
Maximum combined bit rates
(all video streams and recordings)
Rate control
Recording
Recording location
Power requirements
Power connector
Power consumption
Dimensions
Certifications
* When using a display resolution equal to or higher than 1280×720p60, we recommend you use certified high-speed HDMI
cables.
† Unless specified, modes are p60 (progressive 60 Hz).
‡ In 4:2:0 only.
§ Color sampling and color depth limitations may apply. For more information,
¶ Depending on network speed and conditions.
** Maximum: Measured cfg is 4 × 3840 × 2160p30, 4:2:0 or equivalent, excluding power drawn by external USB devices.
Typical: Measured cfg is 4 × 1920 × 1080p60, 4:2:0 or equivalent, excluding power drawn by external USB devices.
¶
Constrained VBR, Configurable group of pictures (GOP)
**
Maevex 6150 encoder
Up to 2560 × 1600 @ 60 Hz
2× 3840 × 2160 @ 60 Hz, 4× 3840 × 2160 @ 30 Hz,
8× 1920 × 1080 @ 60 Hz, 16× 1280 × 720 @ 60 Hz,
or numerous SD IP channels
120 Mbps
800 Mbps
Constant bit rate (CBR), Variable bit rate (VBR),
MP4 file format
NAS device, external USB storage device
+12V to 28V DC, maximum 5 A
(5 A fuse for overcurrent protection)
DIN 4 female (4-pin)
Maximum: 45W
Typical: 37.2 W
21.7 cm × 18.9 cm × 4.3 cm /
8.53 in × 7.45 in × 1.68 in
Class A: ACMA, CE, FCC, ICES, VCCI, Korea
see "Notes and limitations", page
