Overview
Gerber (layout) files are available at www.ti.com.
The EVM is delivered with cables and an Input-USB board to connect to an input source and be controlled
from a PC.
An external power adapter is required for supplying the voltage to the Input USB-2 Control Board. Refer to
the Power Supply Setup
1.1

TAS5342DDV6EVM Features

• 5/6-channel PurePath Digital™ evaluation module
• Subwoofer line output (LFE Output).
• Self-contained protection system (short circuit and thermal).
2
• Standard I S and I
• Double-sided, plated-through PCB layout.
4
TAS5342DDV6EVM
section for more information.
2
C/control connector for TI input board
