Large Tripod Portable Projection Screen
Tripod Stage Series
Thank you for choosing the Tripod Stage portable projection screen! Please read through this user guide
before utilizing the screen. Correct usage and maintenance will ensure a long product life.
Care & Use Instructions
◆ Dust, dirt and scratches on the projection surface will affect the picture quality, please take note
of the points below to prevent that from occurring:
1. Do not touch the projection surface with your hands
2. Do not write or draw on the projection surface
3. Do not use fingers or sharp objects to point on the projection surface; this will damage the
screen material.
4. Use a soft-damp cloth to clean the projection surface; do not use chemical cleaning agents or
alcohol.
5. Use clean water when dampening the cleaning cloth and do not rub against the material to
clean it.
◆After using the screen, disassemble it and store it in the carrying bag provided.
◆To avoid damage and injury, the screen should only be operated by adults.
Accessories List
A. Curtain
Rev. 041217 DR
USER'S GUIDE
www.eliteproav.com
B. Carrying Bag
1
Advertisement
Related Manuals for Elite ProAV T153UWS1-D
Summary of Contents for Elite ProAV T153UWS1-D
- Page 1 Large Tripod Portable Projection Screen Tripod Stage Series USER'S GUIDE Thank you for choosing the Tripod Stage portable projection screen! Please read through this user guide before utilizing the screen. Correct usage and maintenance will ensure a long product life. Care &...
- Page 2 Tripod Screen Parts Diagram Support beam Top Hook and Screen Handle Vertical locking sleeve ring Vertical Extension Bar Double lock structure Screen Material Carrying handle & Screen height adjustment double lock/release tab End Cap Screen case Curtain Tripod Support Legs A.
- Page 3 Rotate the casing so that it is parallel to the ground as shown here. fig.1 fig.2 B. Preparing the tripod screen for projection: Follow the steps below and refer to Fig. 3＆4 Note: At least 2 people are needed to set up the screen. Due to the height of the screen when extended, the use of a stool is recommended to properly hook the handle to the keystone eliminator.
- Page 4 A: Counter-clockwise to unlock B: Clockwise to lock fig,5 fig,6 C. Curtain Installation: Follow the step below and refer to Fig. 7 1. Align the Velcro strip (C) of the curtain to the Velcro strip (D) on the screen’s casing and push along the length of the strips together so that the curtain sticks to the casing.
- Page 5 3. Close the tripod legs by pushing the junction upwards. The casing, extension bar and tripod legs should all be aligned as shown in fig. 8. Store the tripod in the provided carrying bag. Dimensions Table Models Numbers Unit: Inches T153UWS1-D 108.2 114.3 114.3 108.2 111.8 152.3 40.5 57.9...
