P3AG-1932-04ENZ0
FUJITSU Storage
ETERNUS AF650 S2,
ETERNUS AF650
All-Flash Arrays
Operation Guide (Basic)

Advertisement

Table of Contents
loading

Related Manuals for Fujitsu Storage ETERNUS AF650 S2

Summary of Contents for Fujitsu Storage ETERNUS AF650 S2

  • Page 1 P3AG-1932-04ENZ0 FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic)
  • Page 2 This page is intentionally left blank.

  • Page 3: About This Manual

    Preface Fujitsu would like to thank you for purchasing the FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 (here- inafter referred to as ETERNUS AF). The ETERNUS AF is designed to be connected to Fujitsu servers (Fujitsu SPARC Servers, PRIMEQUEST, or PRI- MERGY) or non-Fujitsu servers.

  • Page 4: Naming Conventions

    Windows Server 2008 R2 for Itanium-Based Systems ® ® Microsoft Windows Server 2008 HPC Edition ® ® Microsoft Windows Server 2008 R2 HPC Edition FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...

  • Page 5: Symbols Used In This Manual

    ■ Abbreviations Used in This Manual • "ETERNUS AF650 S2" refers to the FUJITSU Storage ETERNUS AF650 S2 and "ETERNUS AF650" refers to the FUJITSU Storage ETERNUS AF650. • "ETERNUS AF" refers to the ETERNUS AF650 S2 and the ETERNUS AF650.
  • Page 6 The black "Must Do..." circle indicates actions that must be taken. The required ac- tion is both illustrated inside the black disk and written above it (e.g. Unplug). FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED...
  • Page 7 - Be careful that no liquid seeps into the ETERNUS storage system when using cleaners, etc. - Do not use alcohol or other solvents to clean the ETERNUS storage system. Warning layout ribbon FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...
  • Page 8 2.2.4 Powering Off ...............................38 2.3 Using the Setting Change Switches ....................40 Chapter 3 Storage System Monitoring 3.1 Checking LED Status ........................42 FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...
  • Page 9 5.2.1 Maintenance Support Period ..........................48 5.2.2 Replacing Batteries.............................49 5.2.3 Related Service ..............................49 Chapter 6 Troubleshooting 6.1 Check List ............................. 50 6.2 Required Information for Inquiries ....................57 FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...
  • Page 10 OFF Position (Marked "¡") of the PSU Switch of a Power Supply Unit ............36 Figure 3.1 ETERNUS Web GUI Screen .........................42 Figure 3.2 Event Notification ............................44 Figure 3.3 Audit Log..............................45 FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...
  • Page 11 Table 3.2 General Status of ETERNUS CLI .........................43 Table 4.1 Volume Formatting Time..........................46 Table 4.2 Rebuild Process Time..........................47 Table 4.3 Copyback Process Time..........................47 FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...

  • Page 12: Chapter 1 Component Names And Led Names

    ● With a Front Cover Figure 1.1 Front View of a Controller Enclosure (with a Front Cover) Operation panel Front cover Flange cover FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...

  • Page 13: Rear

    This section provides the names of the components in the rear of a controller enclosure. Figure 1.3 Rear View of a Controller Enclosure Controller 0 (CM#0) Controller 1 (CM#1) Power supply unit (CPSU#0) Power supply unit (CPSU#1) FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...

  • Page 14: Components (Front)

    This switch is used to initialize the LAN ports or to initialize the user information. 11. MST SW (CM Master Change switch) This switch is used to change the Master CM. FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...

  • Page 15: Figure 1.5 Battery

    The battery charge rate is 90% or more. (green) (Battery Ready) The battery is being charged or is ready for discharge. (green) (Charge) FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...

  • Page 16: Components (Rear)

    DI (OUT) port This port is used to connect a controller enclosure to a drive enclosure with a mini SAS HD cable between enclosures. FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...

  • Page 17: Figure 1.7 Controller Leds

    DI (OUT) LINK The link between the DI (OUT) port and the destination port has (green) been established. FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...

  • Page 18: Figure 1.8 Host Interface For Fc Cable Connections (4Port)

    Figure 1.9 Host Interface for FC Cable Connections (2port, Equipped with SFP+ Modules in All Ports) CA READY LED CA FAULT LED LINK/FAULT LED Host Interface Port #0 Host Interface Port #1 FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...

  • Page 19: Figure 1.10 Host Interface For Copper Twinax Cable Connections (2Port)

    The link between the host interface port and the destination port (green) has been established. The host interface port is in error status. (amber) FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...

  • Page 20: Figure 1.11 Power Supply Unit (Controller Enclosure)

    LED status Meanings POWER AC power is supplied to the power supply unit. (green) FAULT The power supply unit is in error status. (amber) FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...

  • Page 21: Drive Enclosures

    This section provides the names of the components in the rear of a drive enclosure. Figure 1.13 Rear Views of a Drive Enclosure I/O module (IOM#0) I/O module (IOM#1) Power supply unit (PSU#0) Power supply unit (PSU#1) FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...

  • Page 22: Components (Front)

    ETERNUS Web GUI or ETERNUS CLI. FAULT The drive enclosure is in error status. (amber) POWER DC power is supplied to the drive enclosure. (green) FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...

  • Page 23: Figure 1.15 Drives

    • (amber) The LED light up operation was performed from the ETERNUS • CLI command line in order to identify the drive location. FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...

  • Page 24: Components (Rear)

    The link between the DI (OUT) port and the destination port is in (amber) error status. The ports to connect the cables are indicated. This occurs while a (blinks amber) drive enclosure is being added. FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...

  • Page 25: Figure 1.18 Power Supply Unit (Drive Enclosure)

    FAN FAIL The power supply unit or the fan in the power supply unit is in er- (amber) ror status. FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...

  • Page 26: Inch Racks

    Figure 1.19 Front View of a 19-inch Rack Door handle For instructions on how to open the front door, refer to "2.1.1.1 How to Open the Front Door" (page 30). FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...

  • Page 27: Rear

    Figure 1.20 Rear View of a 19-inch Rack Door handle For instructions on how to open the rear door, refer to "2.1.2.1 How to Open the Rear Door" (page 31). FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...

  • Page 28: Power Distribution Units (For Regions Other Than The Emeia, Central American, And Caribbean Re Gions)

    Inlet (INPUT) This is a socket (IEC60320 C14) for incoming power supply. This socket is used to connect a power cord (AC input cable). FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...

  • Page 29: Power Distribution Units (2U)

    Outlet (OUTPUT) This is a socket (IEC60320 C13) for outgoing power supply. This socket is used to connect a power cord (AC output cable). FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...

  • Page 30: Chapter 2 Basic Operation

    How to Open the Front Door Insert the rack key and turn the key 180 degrees anticlockwise. This will unlock the front door. FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...

  • Page 31: How To Open/Close The Rear Door

    How to Open the Rear Door Insert the rack key and turn the key 180 degrees anticlockwise. This will unlock the rear door. FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...
  • Page 32 How to Close the Rear Door Reverse the opening procedure to close the rear door. Close the rear door with the door handle rotated. FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...

  • Page 33: Powering On And Off

    ● For 2U Figure 2.2 ON Position (Marked "|") of the Main Line Switches on a 2U Power Distribution Unit Main line switch FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...

  • Page 34: Figure 2.3 Off Position (Marked "¡") Of The Main Line Switches On A 1U Power Distribution Unit

    When turning the main line switch to ON (marked "|") right after turning the main line switch to OFF (marked "¡"), turn it back to ON (marked "|") after the POWER LED of the power supply unit has turned off completely. FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...

  • Page 35: Switching On And Off The Psu Switch On The Power Supply Unit

    For the drive enclosure, the POWER LED on the power supply unit emits green lights and the fan revolves at high speed for 30 seconds. Drive enclosure Power supply unit (PSU#0) Power supply unit (PSU#1) POWER FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...

  • Page 36: Powering On

    PSU switches on the power supply units of the ETERNUS AF are "ON". Do not turn the main line switches of the power distribution units and the PSU switches on the ETERNUS AF to the OFF position. FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED...
  • Page 37 Press the Power switch of the controller enclosure. Power switch Controller enclosure The POWER LEDs on the controller enclosure and the drive enclosures are turned on. FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...

  • Page 38: Powering Off

    This section explains how to use the Power switch to turn off the ETERNUS AF. For other procedures, refer to the related manuals. FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...
  • Page 39 When the power is disconnected, the POWER LED of the controller enclosure and the POWER LEDs of the drive enclosures are turned off. FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...

  • Page 40: Using The Setting Change Switches

    The operating procedure for the setting change switches is described below. Remove the flange cover and the front cover of the controller enclosure. Flange cover Front cover FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...
  • Page 41 The MAINTENANCE LED turns off, which indicates that the ETERNUS AF is no longer in maintenance sta- tus. Attach the front cover and the flange cover. FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...

  • Page 42: Chapter 3 Storage System Monitoring

    The status of the ETERNUS AF and the usage status of RAID groups, TPPs, and SDPs can be checked in the Overview screen of ETERNUS Web GUI. Figure 3.1 ETERNUS Web GUI Screen Table 3.1 shows the general status. FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...

  • Page 43: Displaying Status Via Eternus Cli

    An abnormality is detected and access from the host cannot be received. Subsystem Down The ETERNUS AF cannot be used. Change Assigned CM CM hot expansion recovery is required. FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...

  • Page 44: Event Notification

    Figure 3.2 Event Notification Mail server SNMP manager Syslog server E-mail SNMP Trap syslog Host sense Remote Server (host) support center REMCS/AIS Connect ETERNUS AF FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...

  • Page 45: Audit Log

    Figure 3.3 Audit Log Device name Login User/role Process time Setting change Process details Process result Logout etc. Audit log System administrator Syslog server ETERNUS AF FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...

  • Page 46: Chapter 4 Process Time (Estimated)

    *1: The value shows the time required for volume formatting when the volume capacity is 200GB and there is no server I/O. The time that is required depends on the type and configuration of the drive. FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED...

  • Page 47: Rebuild/Copyback Process Time

    Note that RAID group performance (throughput) may be reduced when a rebuild, copyback, or redundant copy is being performed in the target RAID group. FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED...

  • Page 48: Chapter 5 Maintenance

    The standard maintenance support period for ETERNUS AF is five years from the date of purchase, or is de- fined in your service level agreement (SLA). Contact your sales representative for details if you prefer to ex- tend the period. FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...

  • Page 49: Replacing Batteries

    If a possible error that may occur is detected or an error occurs when remote support service is used, the con- tents of events are automatically sent to the remote support center and notified to the user. FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED...

  • Page 50: Chapter 6 Troubleshooting

    Has there been a recent main power failure? If the Power Resume function is enabled, the ETERNUS AF turns on automatically after the power is re- stored. FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...
  • Page 51 Using the FUNCTION button to switch the Master CM Push the CM Master Change switch (MST SW) twice within three seconds during maintenance to switch the Master CM to another controller. FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...
  • Page 52 Change the status of the ETERNUS AF to the maintenance status. Use the pin to push down the CM Master Change switch (MST SW) for three seconds. FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED...
  • Page 53 NUS AF does not respond to SNMP access. Check whether each service can connect to the ETERNUS AF. If it cannot connect, contact your maintenance engineer. FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...
  • Page 54 Force Prefetch mode enabled. Enable the Force Prefetch mode and specify the appropriate value for the Prefetch Limit. This may be caused by accesses that are used for video distribution businesses. FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...
  • Page 55 When a switch is used, the WWN zoning settings need to be changed. For details on this setting, refer to relevant manuals of the switch. After completing the settings, confirm that access from the server is available. FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED P3AG-1932-04ENZ0...
  • Page 56 For details on the replacement procedure, refer to the relevant documentation for the LAN card. After completing the settings, confirm that access from the server is available. FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED...

  • Page 57: Required Information For Inquiries

    ETERNUS Web GUI. For details on obtaining the log/dump information, refer to "Web GUI User's Guide (Settings)". FUJITSU Storage ETERNUS AF650 S2, ETERNUS AF650 All-Flash Arrays Operation Guide (Basic) Copyright 2017 FUJITSU LIMITED...
  • Page 58 However, Fujitsu shall assume no responsibility for any operational problems as the result of errors, omissions, or the use of information in this manual. Fujitsu assumes no liability for damages to third party copyrights or other rights arising from the use of any information •...
