Sun Oracle Netra 6000 Getting Started Manual page 4

2. (Optional) Connect an Ethernet cable between the CMM NET MGT port and the network to which future
connections to the CMM will be made.
After the initial configuration of the system using the SER MGT port, you can connect to ILOM on the CMM
through your network.
▼ Attach Cables to Your Modular Components
Refer to the documentation for each modular component for installation details.
1. For each NEM installed, plug an Ethernet cable into the appropriate RJ-45 Ethernet connector and attach
the other end of the cable to your local area network.
2. For each PCI EM installed, plug the applicable cable into the PCI EM connector and attach the other end
of the cable to your PCI EM network or device.
▼ Apply Power to the Modular System
1. Plug a power cord into each of the four AC power connectors, and plug the other end of each power cord
into your power source.
As soon as power is applied, main power is supplied to the chassis and the installed modular components.
AC power connectors
PS1-AC1
PS1-AC0
PS0-AC1
PS0-AC0
4
