AEG Protect C.3000 Operating Instructions Manual page 77

Dimensions
W x H x D (gross)
(packaging)
Guidelines
Protect C.1000
Protect C.1000 BP
Protect C.2000
Protect C.3000
Protect C.2030 BP
The PROTECT D complies with the
EN 62040 product standard.
The CE seal on the device confirms that the
device complies with the following directives:
EG Low Voltage Directive 2014 / 35 / EU as
well as the EMC Directive 2004 / 108 / EG for
electromagnetic compatibility, if the
installation instructions provided in this
manual are followed.
For 2014 / 35 / EU Low Voltage Directive
Reference number
EN 62040-1: 2008
For 2004 / 108 / EG EMC-Directive
Reference number
EN 62040-2: 2006 Class C1
240 mm x 330 mm
x 495 mm
300 mm x 330 mm
x 500 mm
330 mm x 475 mm
x 590 mm
330 mm x 475 mm
x 590 mm
330 mm x 475 mm
x 590 mm
77
