AEG Protect 3.M 2.0 Manual

Uninterruptible power supply 3-phase input; 3-phase output, 20–120 kva power supply
Hide thumbs


Advertisement

Quick Links

Protect
3.M 2.0
Modular uPs systeM
Uninterruptible Power Supply
3-Phase Input; 3-Phase Output
Networks, workstations, intranet and internet servers,
telecommunications applications and other company
applications must be permanently available. AEG
Protect 3.M 2.0 is the modular UPS solution for IT and
telecommunications. Modern data centers require the
highest levels of efficiency, reliability and flexibility.
Protect 3.M 2.0 provides a technically convincing
and reliable solution to this requirement that can be
modularly adapted to any increasing power demand.
An extension can be made at any time during
operation. The flexible redundancy concept ensures a
steady power supply to any connected devices.
Lower operating costs for energy and cooling with high
efficiency and fast module replacement in the event of power
failure, reduce operational costs and ensure an optimal price
vs. performance ratio for the Protect 3.M 2.0 UPS solution.
20 –120 kVA power supply

Key features

»
Modular design allows for flexible adaption
to the current power demand
»
Up to 95 % efficiency in "online double conversion"
mode, up to 98 % in ECO mode
»
IGBT technology, input power factor >0.99
»
Low phase effect <3 %
»
Redundant control and n+x parallel
redundancy for high availability
»
Parallel operation of up to 4 UPS units (max. 480 kVA)
»
Module installation and removal during operation
("hot swappable")
»
Graphical LCD screen
»
Built-in manual bypass, separate input for bypass power
»
Load dependent fan speed
»
Small footprint

Advertisement

loading

  Summary of Contents for AEG Protect 3.M 2.0

  • Page 1: Key Features

    Modular design allows for flexible adaption applications must be permanently available. AEG to the current power demand Protect 3.M 2.0 is the modular UPS solution for IT and » telecommunications. Modern data centers require the Up to 95 % efficiency in “online double conversion”...
  • Page 2 Almost all labor and Protect 3.M 2.0 is an Protect 3.M 2.0 is based production processes today uninterruptible power supply on high efficiency IGBT are based on high capacity of the highest reliability.
  • Page 3 Classification VFI SS 111 acc. to IEC 62040-3 Protect 3.M 2.0 Power type rating 20 kVA 40 kVA 60 kVA 80 kVA 100 kVA 120 kVA 16 kW 32 kW 48 kW 64 kW 80 kW 96 kW SyStEM Nominal input current...
  • Page 4: Battery Management

    Protect 3.M 2.0 Intelligent Protect 3.M 2.0 communication Interfaces Customer Benefits » Protect 3.M 2.0 contains a 6 integrated remote signal Modular concept powerful communications contacts » The UPS output can be easily module that readily supplies » RS232 interface...
