Metra Electronics 95-7378B Installation Instructions

Kia sportage 2017-up (with 5” screen)

Download this manual

INSTALLATION INSTRUCTIONS FOR PART 95-7378B

Kia Sportage 2017-up

KIT FEATURES

• ISO DDIN radio provision

• Painted scratch resistant matte black

KIT COMPONENTS

• A) Radio trim panel • B) Radio brackets

WIRING & ANTENNA CONNECTIONS (sold separately)

Wire harness: • 70-7304

Antenna adapter: • 40-KI11

METRA – The World's best kits.

(with 5" screen)

95-7378B

metraonline.com

Table of Contents

Dash Disassembly ................................................. 2

Kit Preparation ....................................................... 3

Kit Assembly .......................................................... 3

TOOLS REQUIRED

• Panel removal tool • Phillips screwdriver

• Torx screwdriver

CAUTION!

All accessories, switches, climate controls panels, and

especially air bag indicator lights must be connected before cycling

the ignition. Also, do not remove the factory radio with the key in the

on position, or while the vehicle is running.

Need help?

Do you have a question about the 95-7378B and is the answer not in the manual?

Page 1 INSTALLATION INSTRUCTIONS FOR PART 95-7378B Table of Contents Kia Sportage 2017-up (with 5” screen) 95-7378B Dash Disassembly ..........2 Kit Preparation ............3 Kit Assembly ............3 KIT FEATURES • ISO DDIN radio provision • Painted scratch resistant matte black...
Page 2: Dash Disassembly
95-7378B Dash Disassembly 1. Unclip and slide the top of the center console (including the cup holders) back slightly. (Figure A) 2. Open the passenger door, and then unclip and remove the dashboard trim panel. Remove (1) Phillips screw exposed. (Figure B) 3.
Page 3: Kit Preparation
(Figure A) radio using the screws supplied with the radio. (Figure A) 2. Attach the 95-7378B radio trim panel to the factory radio/vent panel, and then secure using the factory hardware. (Figure A) 2. Locate the factory wiring harness...
Page 4 INSTALLATION INSTRUCTIONS FOR PART 95-7378B IMPORTANT If you are having difficulties with the installation of this product, please call our Tech Support line at 1-800-253-TECH. Before doing so, look over the instructions a second time, and make sure the installation was performed exactly as the instructions are stated.
