INSTALLATION INSTRUCTIONS FOR PART 95-7337B

95-7337B

KIT FEATURES

• DDIN Head Unit Provision

• ISO Stacked Head Unit Provision

• Painted Matte Black

KIT COMPONENTS

A) Double DIN Trim Plate B) Double DIN Brackets

WIRING AND ANTENNA CONNECTIONS (Sold Separately)

• 70-7303 - Kia / Hyundai Harness 2009-up

• 40-KI11 - Kia / Hyundai Antenna Adapter 2007-up

• Small Flat Blade Screwdriver • Panel Removal Tool

1-800-221-0932

APPLICATIONS

KIA Soul

2010

Harness:

Antenna Adapter:

TOOLS REQUIRED:

• Phillips Screwdriver

www.metraonline.com

METRA ELECTRONICS CORPORATION

Need help?

Do you have a question about the 95-7337B and is the answer not in the manual?

Page 1 INSTALLATION INSTRUCTIONS FOR PART 95-7337B 95-7337B KIT FEATURES • DDIN Head Unit Provision • ISO Stacked Head Unit Provision • Painted Matte Black KIT COMPONENTS A) Double DIN Trim Plate B) Double DIN Brackets WIRING AND ANTENNA CONNECTIONS (Sold Separately) •...
Page 2 Final Assembly ......... . 3 *Note: Refer also to the instructions included with the aftermarket radio. 95-7337B NOWLEDGE IS Enhance your installation and fabrication skills by enrolling in the most recognized and respected mobile electronics school in our industry.
Page 3 95-7337B DASH DISASSEMBLY isconnect the negative battery ter- minal to prevent an accidental short circuit. Unclip and remove the radio/climate control trim panel. (Figure A) Remove (4) Phillips screws securing the climate control. (Figure B) Remove (4) Phillips screws securing the radio.
Page 4 Attach the Double DIN brackets to the Double DIN Trim Plate. (Figure A) Slide the radio into the bracket/radio housing assembly and secure using the screws supplied with the radio. (Figure B) Reassemble dash in reverse order of disassembly. 95-7337B KIT ASSEMBLY PROVISIONS...
Page 5 95-7337B INSTRUCTIONS NOTES...
Page 6 95-7337B INSTRUCTIONS NOTES...
Page 7 95-7337B INSTRUCTIONS NOTES...
