INSTALLATION INSTRUCTIONS FOR PART 95-7330
APPLICATIONS
KIA Spectra/Spectra 5 2007
95-7330
KIT FEATURES
• Double DIN Radio Provision
• Stacked ISO Mount Mount Units Provision
KIT COMPONENTS
A) Double DIN Trim Plate B) Double DIN Brackets
A
B
TOOLS REQUIRED:
Small Flat Blade Screwdriver/ Panel Removal Tool
• Phillips Screwdriver
1-800-221-0932
www.metraonline.com
© COPYRIGHT 2004-2007 METRA ELECTRONICS CORPORATION
Advertisement
Related Manuals for Metra Electronics 95-7330
Summary of Contents for Metra Electronics 95-7330
- Page 1 INSTALLATION INSTRUCTIONS FOR PART 95-7330 APPLICATIONS KIA Spectra/Spectra 5 2007 95-7330 KIT FEATURES • Double DIN Radio Provision • Stacked ISO Mount Mount Units Provision KIT COMPONENTS A) Double DIN Trim Plate B) Double DIN Brackets TOOLS REQUIRED: Small Flat Blade Screwdriver/ Panel Removal Tool •...
- Page 2 Final Assembly ......... . 3 *Note: Refer also to the instructions included with the aftermarket radio. 95-7330...
- Page 3 Unclip and remove the trim panel sur- rounding the radio and including the a/c vents. (Figure A) Remove (4) Phillips screws securing the radio. Unplug and remove radio. (Figure B) Continue to kit assembly. 95-7330 DASH DISASSEMBL Y...
- Page 4 ISO mount units into the bracket/trim plate assembly and secure the radio or ISO mount units to the assembly using the screws supplied with the radio or ISO mount units. (Figure B) Continue to final assembly. 95-7330 KIT ASSEMBL Y...
- Page 5 *NOTE: When a Black wire is not present, ground radio to vehicle chassis. All colors may not be present on all leads due to manufacturer’s specifications. 95-7330 FINAL ASSEMBL Y (A) Strip wire ends back 1/2" B) Twist ends together...
- Page 6 95-7330 NOTES...
- Page 7 95-7330 NOTES...
- Page 8 95-7330 INSTRUCTIONS 1-800-221-0932 www.metraonline.com REV. 09/11/07 © COPYRIGHT 2004-2007 METRA ELECTRONICS CORPORATION INST95-7330...
