EventLITE 7/4

Bottom

06) 3-pin DMX signal connector OUT
07) 3-pin DMX signal connector IN
08) IEC Power connector OUT
09) Power switch ON/OFF
10) IEC Power connector IN + Fuse 5S 1,5A/250V

Installation

Remove all packing materials from the
removed. Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.

Set Up and Operation

Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.

Charging the built-in battery

01) In order to charge the battery, you need the included IEC power cable.
02) Turn off the power.
03) Connect the EventLITE to the IEC power cable.
04) Then plug the other end of the IEC power cable into a proper electric power supply socket.
05) Charge the battery within 10 hours.
Important!
• Do not charge for more than 24 hours.
• Recharge within 3 days of use.
• Turn off the power on/off switch at the underside when storing for more than 7 days.
• Store in an upright position.
Ordercode: 44005
EventLITE 7/4. Check that all foam and plastic padding is
9
Fig. 03
