BETA – IsatDock Drive/Lite Overview

1. Overview

There are four main variants of the IsatDOCK docking stations:
1. IsatDock LITE
The IsatDock LITE docking station provides a high quality mechanism for docking the
Inmarst IsatPhone Pro handset. The dock is targeted for an in-vehicle application that
connects to an external vehicle-mount antenna The IsatDock LITE allows the option of using
an optional privacy mode handset mounted alongside the unit.
2. IsatDock DRIVE
The dock is design specifically for an in-vehicle handsfree application, connecting to an
external vehicle-mount antenna The IsatDock DRIVE allows for the use of an optional
privacy mode handset mounted alongside the unit or an external speaker and microphone.
The IsatDock DRIVE incorporates inbuilt GPS tracking and the following additional external
interfaces: an alert loop, radio muting, and horn alerts.
3. IsatDock PRO
The IsatDock PRO allows the flexibility of using a privacy mode handset mounted to the unit
or an RJ11/POTS handset connected directly to the rear. The user is also able to operate in
a hands free mode with a microphone and speaker combination build into the dock. The
installation options of the IsatDock PRO enable the user to mount the IsatDock PRO in
either a vertical or horizontal position.
4. IsatDock MARINE
The IsatDock MARINE docking station allows the flexibility of using a privacy mode handset
mounted to the unit or an RJ11/POTS handset connected directly to the unit. The terminal
itself is designed with IP rating for use in harsh environments. The IsatDock DRIVE
incorporates inbuilt GPS tracking and an alert loop function.
