BETA – IsatDock Drive/Lite Overview
3.4.

Adjusting LED Brightness

Pressing the UP and DOWN buttons together will put the docking station into LED brightness
adjustment mode. Once in this mode the LED's will flash. Press UP or DOWN to increase or
decrease the LED brightness to a comfortable level, depending on your environment. This mode
will automatically timeout after 5 seconds of button inactivity.
3.5.

Keylock

A barrel type lock is situated in the top of the dock. When locked, the eject button cannot be
depressed and the latch holding the top of the handset in position cannot be disengaged from the
IsatPhone Pro. Once locked, the access to the security bolt beneath the handset is also denied
thus ensuring the PRO/MARINE docking stations cannot be removed from their mounting bracket.
O
O
P E N
P E N
Figure 5 – Keylock position
Page 11 of 25
L
L
O C K E D
O C K E D
Beam Communications
STRICTLY CONFIDENTIAL
