4. Installation

4.1.

Privacy Handset

The privacy handset is an accessory that allows users to make private calls. The privacy handset is
used in conjunction with a mounting cup, that detects when the handset is ON or OFF hook.
The Privacy Handset should reside in the privacy handset cup when not in use.
In harsh environments, the Privacy handset is actively retained in the mounting cup. This is
achieved by using the 'sprung' mounting cup. To remove the handset from the cup, the phone is
lifted up against the pressure of the spring until it clears the lower mounting pip and can be
removed from the docking station.
Page 12 of 25
The privacy handset can be
mounted to either the left or right
Figure 6 – Privacy Handset mounting cup
