BETA – IsatDock Drive/Lite Overview
5
6
The Privacy Handset connects to the docking station via a RJ9 connector.
Page 14 of 25
The mounting arm and privacy handset is now
attached to the IsatDock.
Insert the privacy handset cup cover to complete
the assembly
Figure 7 – Privacy Handset connection point
Beam Communications
STRICTLY CONFIDENTIAL
LITE / DRIVE
