Facility Requirements Guide
Please refer back to
http://infocenter.3dsystems.com/projetmjp5600/facility-requirements-guide
most up-to-date Facility Requirements Guide
About this manual
This document includes all of the overall facility requirements that will be needed to have a successful
installation when our 3D Systems Field Service Engineer or 3D Systems certified servicing reseller
arrive to install your 3D printer.
®
ProJet
MJP 5600
Facility Requirements Guide
Rev D
Original Instructions
for the
Advertisement
Table of Contents
Related Manuals for 3D Systems ProJet MJP 5600
Summary of Contents for 3D Systems ProJet MJP 5600
- Page 1 About this manual This document includes all of the overall facility requirements that will be needed to have a successful installation when our 3D Systems Field Service Engineer or 3D Systems certified servicing reseller arrive to install your 3D printer.
-
Page 2: What Is A Facility Requirements Guide
What is a Facility Requirements Guide This guide provides important information on selecting a facility location and planning for the installation of 3D Systems' ProJet® Professional Printing System. It also presents planning guidelines to facilitate fast, convenient installation and operation of your printer. -
Page 3: Safety Symbols And Definitions
Symbols Used In This Guide Safety Symbols and Definitions READ SYMBOL: Read the Service Manual before opening doors or removing panels. Access panels are for Service only and should be opened only by certified service personnel or trained maintenance personnel. UV RADIATION HAZARD: Invisible UV radiation is accessible in the vicinity of this sign or behind the panel. - Page 4 The ProJet Professional Printing System ® The ProJet Professional Printing System consist of the following components, providing these functions: Outputs 3-dimensional prints from digital data supplied to the printer in the required .stl file format, using one or a two-material process. One licensed copy of 3D SPRINT™...
- Page 5 This section provides detail relating to site selection, site preparation and readiness of the facility to accept and install the printer. Discuss the appropriate equipment locations with a 3D Systems' representative, so that the equipment is located in a convenient, appropriate location based on your organization's needs.
-
Page 6: Unit Portability
CAUTION: Once the printer is installed, it cannot be moved without the aid of a qualified, 3D Systems Field Service Engineer or 3D Systems certified servicing reseller. 3D Systems accepts no responsibility for damage to the printer by... -
Page 7: Power Requirements
NOTE: All 240VAC markets require a step down transformer with 100-120VAC output for proper heater control. Please have 3D Systems direct or partner order the correct nationalization kit. The installation of the printer shall comply with the National Standards and/or Electrical Codes of the country in which it is placed. - Page 8 Additionally, each printer's subnet mask and default gateway must be known and available to the 3D Systems Field Service Engineer or authorized reseller at the time of installation, and should also be known by personnel installing the client software. They will need access either to the appropriate subnet mask or the individual IP address of each printer to complete the workstation software installation, and to enable access to any printer on the network.
- Page 9 3D Systems’ Customer Hotline here. Material Bottle Disposal Used part material bottles must be disposed of in a manner consistent with local and other applicable laws and regulations governing such materials. Refer to the VisiJet® materials' sheets prior to shipment of the ProJet™...
-
Page 10: Air Conditioning
Operating Environment Locate the printer in a convenient location meeting the requirements specified in this document. The printer is designed for indoor use only. To ensure optimum performance, it is important that the printer must be installed in a clean, dry, air-conditioned room. Avoid placing the printer in any environment with airborne contaminants, including cigarette smoke, fumes, and mechanical particulates that can adversely affect the long term functioning of this equipment. - Page 11 System needs to be shipped back to the manufacturer for repair. These crates are designed to allow fast, easy removal and packaging of the product. If printer needs to be return to the manufacturer, contact 3D Systems Customer Support for shipping instructions.
-
Page 12: Printer Advance Preparation Checklist
Printer Advance Preparation Checklist Unless governed by prior arrangement, 3D Systems is not responsible for loading the client software on the user's workstation(s). BEFORE THE PRINTER ARRIVES, ensure that your workstation is capable of supporting the requirements of both the client software and communication with the machine via your network. - Page 13 3D Systems' Customer Service Representative. If alteration are made without consulting 3D Systems, it may void the system's warranty. Customer Signature: _________________________________________________________ Date: _______________...
-
Page 14: Limitation Of Liability
This limitation will apply even if 3D Systems or an authorized dealer or representative has been otherwise advised of the possibility of such damage. This document, in whole or in part, may be changed or modified at any time at the sole discretion of 3D Systems, without notice. - Page 15 Thank You ® 3D Systems is confident that you will be very satisfied with the purchase of your ProJet Professional Printing System. Enjoy the ability to produce high quality parts from your 3-D digital data. We are dedicated to developing a relationship that extends beyond the terms of the sale. Please take the time ®...
-
Page 16: Contacting 3D Systems
International: +1 803-326-3930 General ProJet® MJP 5600 service procedures must be performed only by a 3D Systems-certified service technician unless this guide explicitly states otherwise. If your 3D printer system needs service, contact 3D Systems Technical Support at the following numbers:...
