Altronix HubSat4WP Installation Manual page 12

6"
152.4mm
13"
14"
355.6mm 330mm
4.21"
107mm
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056
website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A.
IIHubSat4WP
- 12 -
Enclosure Dimensions
12" x 8" x 6" (304.8mm x 203.2mm x 152.4mm)
8"
203.2mm
4.05"
103mm
(H x W x D approximate)
MOUNTING PANEL
GALVANIZED
12"
305mm
K15Q
:
6.7"
170mm
CARBON STEEL SHEET
9.84"
250mm
0.08"
2mm
MEMBER
HubSat4DWP
