SMP 111 Power Up Procedure
NOTE: Before powering the SMP 111, ensure that all necessary devices are connected
Connect the power cord to a 100 to 240 VAC supply (see
page 10).

Record a File

The SMP 111 creates MP4, M4V, and M4A media files. Recordings are stored to the 32GB
internal storage or to storage media connected to the front, rear, or RCP 101 USB ports.
The recording location defaults to the internal storage.
The internal 32GB SD card is field upgradable to different storage sizes. For instructions to
replace the SD card, see
To configure an ad hoc recording:
1.
2.
3.
4.
5.

Front Panel Lockout (Executive Mode)

To prevent accidental changes to front panel menu settings, enable executive mode.
Executive mode can be enabled and disabled from the front panel. Press the Stop and
Mark buttons simultaneously for 5 seconds. It can also be enabled or disabled from the
web pages or using SIS (see
(Executive Mode)
When executive mode is enabled, any attempts to utilize the front panel buttons triggers the
Record, Pause, Stop and Mark LEDs to blink 3 times.
When executive mode is active, all functions and adjustments can still be made via USB,
RS-232, or Ethernet control (see
page 63).
NOTE: Control buttons indicate the current recording or streaming status regardless of
properly. Devices do not need to be powered.
Upgrading the SD Card
Press the front panel Record button.
Monitor the record time and remaining time on the embedded web page.
Press Pause to temporarily suspend recording. Press Pause again or Record to
resume the recording and place a chapter marker in the file.
Press Mark to create a chapter marker and a thumbnail if desired.
Press Stop to cease recording and place an end of file maker on the recording.
System Settings
on page 71
executive mode.
Power Connection
on page 106.
on page 50 or
Remote Communication and Control
SMP 111 • Front Panel Operation
on
Front Panel Lock
starting on
17
