Push Stream and Pull Stream Playback URLs
To verify a running stream, use the templates below to place the stream into the VLC "Open
Network Stream" dialog (see step 5 of
on page 99).
Pull Stream URLs
PULL Streaming:
RTSP Unicast
RTSP Multicast
Push Stream URLs
PUSH Streaming:
Unicast (Destination IP must be set to the location where the stream is played)
TS/UDP
TS/RTP
ES/RTP
Multicast (Destination IP must be multicast IP address)
TS/UDP
TS/RTP
ES/RTP
NOTES:
• <SMP111_IP> is the IP address of the SMP 111.
• <DESTINATION_IP>:<DESTINATION_PORT> are the IP address and port
number of the destination.
• <stream name> is the file name.
• Some dependencies may apply with certain versions of VLC. For ES/RTP push
streams, SAP is available in "video Only" stream mode.

Streaming Capabilities and System Scalability

The following tables detail the streaming capabilities of the SMP 111. Data for the tables
was obtained through laboratory testing using optimal bandwidth conditions and can vary
depending on the selected video bit rate.
NOTE: Testing to determine the approximate maximum number of pull streams
was done on the encoder with one pull unicast Streaming stream. Recording while
streaming does not reduce the maximum number of pull streams.
Available Unicast Streams
Video resolution and bit rate affect the total number of unicast streams the SMP 111 can
broadcast. The following table compares the selected resolution and bit rate with the
approximate number of unicast streams that will be available. Changing the resolution or
using higher or lower bit rates may increase or decrease the available number of streams.
Playing a Pull Stream Using VLC Media Player
URL
rtsp://<SMP111_IP>/<stream name>
rtsp://<SMP111_IP>/<stream name>/multicast
or
HTTP://<SMP111_IP>/live/pull/multicast.sdp
URL
UDP://@:<Destination_Port>
RTP://@:<Destination_Port>
HTTP://<SMP111_IP>/live/push/s3.sdp
UDP://@<Destination_IP>:<Destination_Port>
RTP://@<Destination_IP>:<Destination_Port>
HTTP://<SMP111_IP>/live/push/s3.sdp
SMP 111 • Reference Information 97
