User Guide
Streaming AV Products
VN-Matrix
250 Series
®
VNE 250 Encoder and VND 250 Decoder
68-2236-01 Rev. E
01 19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VN-Matrix 250 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Extron electronics VN-Matrix 250 Series

Summary of Contents for Extron electronics VN-Matrix 250 Series

  • Page 1 User Guide Streaming AV Products VN-Matrix 250 Series ® VNE 250 Encoder and VND 250 Decoder 68-2236-01 Rev. E 01 19...
  • Page 2 Safety Instructions Istruzioni di sicurezza • Italiano Safety Instructions • English WARNING: This symbol, , when used on the product, is intended AVVERTENZA: Il simbolo, , se usato sul prodotto, serve ad to alert the user of the presence of uninsulated dangerous voltage avvertire l’utente della presenza di tensione non isolata pericolosa within the product’s enclosure that may present a risk of electric shock.
  • Page 3 All trademarks mentioned in this guide are the properties of their respective owners. The following registered trademarks®, registered service marks(SM), and trademarks(TM) are the property of RGB Systems, Inc. or Extron Electronics (see the current list of trademarks on the page at Terms of Use www.extron.com...
  • Page 4 FCC Class A Notice This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. The Class A limits provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 5 Conventions Used in this Guide Notifications In this user guide, the following are used: WARNING: Potential risk of severe injury or death. AVERTISSEMENT : Risque potentiel de blessure grave ou de mort. CAUTION: Risk of minor personal injury. ATTENTION : Risque de blessure mineure.

  • Page 7: Table Of Contents

    Contents Low Level Device Configuration ....25 Introduction ............1 Initial Configuration ........25 About this Guide ..........1 Setting a VNM 250 Device as the About the VNM 250 ......... 1 System Controller ......... 28 VNM 250 System Controller ......3 Configuring the System Controller with Transport Protocols Used for Streaming ..
  • Page 8 Bandwidth Management Alarms ............112 – Advanced Control ........70 Alarm Types ..........112 Configuring Encoder Audio ......71 Alarm Handling ..........114 Configuring Encoder Data ......72 Configuring a VND 250 ........73 Troubleshooting .........115 Configuring the Decoder Display ....74 Monitoring the Decoder Video Front Panel Status Indicators .......

  • Page 9: Introduction

    Introduction This section provides an overview of the user guide and describes the Extron VN-Matrix (VNM) 250 series. Topics that are covered include: About this Guide • About the VNM 250 • VNM 250 System Controller • Transport Protocols Used for Streaming •...
  • Page 10 The VNM 250 series also supports a reverse audio channel for collaborative applications where 2-way communication is required. The VND 250 video output is available only in digital format. It can be configured to display at the same resolution and refresh rate as the encoder input or it can be scaled to match the requirements of the display attached to the decoder.

  • Page 11: Vnm 250 System Controller

    VNM 250 System Controller All matrix systems require one device that acts as the system controller. For small systems (ten devices or fewer), this can be either a VNE 250 or VND 250. For larger systems, a VN-Matrix Enterprise Controller must be used. Systems Controlled by Systems Controlled by VNM Enterprise Controller...

  • Page 12: Multicast Rtp - An Overview

    Multicast RTP — An Overview Multicast RTP allows a source to be displayed on multiple displays. This method uses a real-time variation of UDP called RTP (Real-time Transport Protocol). RTP (m) RTP (m) Network ADJUST ADJUST MENU CONTROL MENU CONTROL STREAM STREAM STATUS...

  • Page 13: Unicast Rtp - An Overview

    Unicast RTP — An Overview Similar to multicast RTP, this method uses a real-time variation of UDP protocol, called unicast RTP. This method can be used where the network infrastructure does not support multicast traffic. Typically, this protocol is used for point-to-point configuration (single source to single display), but can be configured to use up to a maximum of four displays.

  • Page 14: Definitions

    Definitions PURE3 — is specifically designed for network transmission of real time media (such as video or graphics, audio, data, and whiteboard elements). It features both spatial and temporal image compression, which allows for efficient bandwidth usage. PURE3 streams always contain video or graphic elements. •...
  • Page 15 Unicast or multicast streaming — supports scalability and compatibility with different • network operating conditions. PURE3 Codec — low-latency, visually lossless compression offering efficient bit rates, • and high immunity to network errors for streaming very high quality video with low delay over IP networks.
  • Page 16 Front panel LEDs — offers quick visual indication of device, system, or streaming • status to simplify commissioning activities and troubleshooting. VLAN tagging — simplifies management of encoders and decoders, making • management and operation on multi-purpose networks simple. Local Ethernet control port — offers the flexibility to connect a control device to the •...

  • Page 17: Installation Overview

    Installation Overview This section provides an overview of the installation process. To set up the VNE 250 and VND 250, follow these instructions and the instructions referenced by the links provided: If required, install small form-factor pluggable (SFP) connectors in the LAN 2 ports (see Streaming Network on page 17).
  • Page 18 Connect all the VNM 250 units to the network (see Network Connections page 16). NOTES: • Ensure that the LAN 2 port is connected to the designated streaming network. • The control port is used with IP Link or third-party control devices. A control port connection is not required for normal operation of the VNM 250 unit.

  • Page 19: Front Panels

    Front Panels This section describes VNM 250 Front Panels • Status Information • Unit Identify Mode • VNM 250 Front Panels The front panels of both the VNE 250 and the VND 250 are identical apart from the product name on the silk screen. The VNE 250 is shown below: ADJUST MENU CONTROL...

  • Page 20: Status Information

    Status Information Name Color Function Orange Control Indicates the status of the control network port: Fully lit or flashing intermittently — control data is being transmitted or received by the port. Unlit — no data or no network connection detected. Orange Stream Indicates the status of the active network port (streaming):...

  • Page 21: Rear Panel And Connections

    Rear Panel and Connections This section describes the VNE 250 and VND 250 rear panels and the connectors: VNE 250 Rear Panel • VND 250 Rear Panel • Connections • VNE 250 Rear Panel INPUT 2 LAN 1 LOOP AUDIO RETURN AUDIO THRU INPUT 1...

  • Page 22: Connections

    Connections Power The provided 12 VDC, 3 A power supply connects to a 2-pole, 3.5 mm captive screw receptacle on the rear panel of the encoder (see figure on page 13), or decoder (see figure 7,  on page 13). Connect the captive screw connector from the power supply to the power receptacle. CAUTION: The two power cord wires must POWER...
  • Page 23 ATTENTION: • These power supplies are not suitable for use in air handling spaces or in wall cavities. The power supply is to be located within the same vicinity as the Extron AV processing equipment in an ordinary location, Pollution Degree 2, secured to the equipment rack within the dedicated closet, podium, or desk.

  • Page 24: Network Connections

    Network Connections figure 6 figure , and LAN 1 The VNM 250 series units have two separate network connectors: one for the control network (LAN 1) the other for the streaming network (LAN 2). Each port has its own IP address. The control port (LAN 1) is not required for normal operation.
  • Page 25 Streaming network (LAN 2) NOTE: The RJ-45 and SFP streaming network connectors share the same IP address. Only one connector can be active at any time. If the SFP cage is unpopulated, the RJ-45 connector is active. If the SFP cage is populated, it becomes active and the RJ-45 connector is inactive.

  • Page 26: Usb Ports

    USB Ports KVM function KVM functionality permits remote collaboration between different endpoints on the network by allowing a mouse and keyboard connected to the decoder to control a PC connected to the encoder using the rear panel USB ports. Connect a mouse and keyboard to the VND 250 rear panel USB ports (see figure 7, ...

  • Page 27: Coms

    Coms RS-232 pass-through The Coms port on the rear panel of the encoder (see figure on page 13), or decoder (see figure 7,  on page 13) is used for RS-232 pass-through communications, allowing a control device connected to one VNM 250 unit to control a remote device connected to a second VNM 250 unit.

  • Page 28: Alarms

    RS-232 control RS-232 control — allows low level configuration of the encoder or Tx Rx Tx Rx G Tx Rx decoder. Use the three poles to the right of the shared captive screw connector (see figure , or figure on page 13). See the Attention notifications on page 15 for information about preparing PASS THRU CONTROL...

  • Page 29: Video Connections

    Connect the ground connector of the first slave device to the ground connector of the second slave device. Connect the genlock out from the first slave device to the genlock in of the second slave device. Repeat steps 5 and 6 to link as many slave devices as required. Video Connections HDMI input (VNE 250) —...

  • Page 30: Audio Connections

    Audio Connections Audio loop-through (VNE 250) — INPUT 2 LOOP AUDIO RETURN AUDIO THRU connect a 3.5 mm TRS jack to this socket for unbalanced buffered output from the audio input source (see figure 6,  on page 13). Analog program audio input LOOP THRU (VNE 250) —...

  • Page 31: System Configuration With The Enterprise Controller

    System Configuration with the Enterprise Controller All Matrix systems require one device that acts as the system controller. For a small system (ten devices or fewer), this can be either a VNE 250 or VND 250. For larger systems a VN-Matrix Enterprise Controller must be used.
  • Page 32 The Enterprise Controller GUI opens. Figure 10. VN-Matrix Enterprise Controller Device List To configure the system with the Enterprise Controller, see the VN-Matrix Enterprise Controller User Guide, which is available at www.extron.com. VNM 250 • System Configuration with VNM Enterprise Controller...

  • Page 33: Low Level Device Configuration

    Low Level Device Configuration This section discusses: Initial Configuration • Setting a VNM 250 Device as the System Controller • Configuring a VNM 250 Series Unit for DHCP • Using a Dedicated DHCP Server • Configuring a Windows 2008 R2 •...
  • Page 34 The low level configuration menu opens (figure 11 shows default values): Control Network port Streaming Network port ==================== ====================== 0. Speed/Duplex: auto_10_100_1000 10. Speed/Duplex: auto_10_100_1000 1. IP Prov mode: static [dhcp] 11. IP Prov mode: static [dhcp] 2. address: 192.168.253.254 12.
  • Page 35 To clear a Gateway Address, select and press < > with no value set. Enter Options , and are not available. • — these options set the Maximum Transmission Unit (MTU) Setting. The • default value is 1500 This value affects the system performance. Larger values may cause packets to be fragmented (split) and smaller values may not make efficient use of the network capacity.

  • Page 36: Setting A Vnm 250 Device As The System Controller

    — this option sets the DHCP IP range and is only available when DHCP is • enabled (option ). Enter the DHCP pool address range in the following format: < > xxx.xxx.xxx.xxx space xxx.xxx.xxx.xxx where the lower IP address value and the upper IP address value are separated by a single space.

  • Page 37: Configuring A Vnm 250 Series Unit For Dhcp

    Configuring a VNM 250 Series Unit for DHCP VNM 250 devices can have their streaming port network settings configured using IP addresses from a DHCP server. For small systems, the VNM 250 device that is used as the system controller can also be configured to act as a DHCP server.

  • Page 38: Configuring A Vnm 250 Series Unit To Operate With A Dhcp Server

    Select option to move to the controller section of the menu. 6. DHCPD/SLAAC server enable: none 9. Exit Please select an option: Figure 14. Low Level Configuration Menu, Page 2 Select option and enter . This enables the DHCP server in the device. dhcp Once option is set to...

  • Page 39: Using A Dedicated Dhcp Server

    Select option (Exit) to enter the controller menu. 6. DHCPD/SLAAC server enable: none 9. Exit Please select an option: Figure 17. Low Level Configuration Menu, Page 2 Ensure that options 6 is set to none Select option (Exit) to reboot the device. The streaming network settings is configured when the VNM 250 device is connected to a network with a properly configured system controller or DHCP server.

  • Page 40: Configuring A Windows 2008 R2

    Configuring a Windows 2008 R2 The windows DHCP server can be configured so that when a VNM 250 device contacts the server for an IP address, the server can include the IP address of the system controller and the controller port number as part of the DHCP configuration. The figure below shows a Windows Server 2008 R2 installation.

  • Page 41: Control Port

    Control Port The control port is used to access the web UI or the HLI control interfaces on a VN-Matrix system. The web UI on either a VNM 250 device (configured as the system controller) or a VNM Enterprise controller can be accessed from any device on the same system by connecting a PC to a properly configured control port.

  • Page 42: Vnm 250 Gui Overview

    VNM 250 GUI Overview This section discusses: VNM 250 GUI Login • VNM 250 GUI Tabs • Tabs Shared by Both the Encoder and Decoder • Encoder Tabs • Decoder Tabs • VNM 250 GUI Login The system can be configured and controlled using a GUI, which is served by the VNM 250 device that is acting as the system controller.

  • Page 43: Vnm 250 Gui Tabs

    VNM 250 GUI Tabs The following list shows the tabs that are available in the VNM 250 GUI control interface and provides links to more detailed descriptions of each tab. They are divided into Shared tabs (encoder and decoder), Encoder tabs, and Decoder tabs. Configuration of the system, using the control interface is described in Configuration with the VNM 250 GUI...

  • Page 44: Tabs Shared By Both The Encoder And Decoder

    Tabs Shared by Both the Encoder and Decoder Some of the tabs listed in this section, for example the Device List (see below), Accounts (see page 37), Alarms (see page 38), and Alarm Logs tabs (see page 39), can be accessed without first selecting a device.
  • Page 45 Click on any of the text or icons for a specific device to open the tab for that device. Device For information about the encoder Device tab, see page 46. For information about the decoder Device tab, see page 58. Accounts tab —...
  • Page 46 Clock Management NOTE: The Current Time is the date and time when the page was served. (see figure on the previous page) is used by all devices to time Current Time stamp system events and alarms. The clock setting on all VNM 250 devices is factory set to UTC time and it is not necessary to make any changes to the setting for the system to operate.
  • Page 47 Alarms are descriptions of problem events with the system. They are raised and cleared by hardware and typically have a 5 second hysteresis — once an alarm is raised, it stays on for 5 seconds even though the error event has cleared. This prevents noisy conditions saturating the alarm log buffer.
  • Page 48 The system contains space for 200 alarm logs. Once more than this number of events have been recorded the history of older events are discarded. Alarm logs can also be cleared by clicking the button. Clear Logs Alarm logs can be sorted by type, raise time and severity by clicking on the column header. A small arrow shows the sort direction which is reversed when the column header is clicked a second time.
  • Page 49 SNMP Community The value in the field acts as a password. It is used to authenticate SNMP Community messages between the VNM 250 system and the network management system (NMS). By default, the field is set to public. The SNMP Community string must match SNMP Community that in use by the NMS;...
  • Page 50 Peripherals tab To access the tab, you must first select a device from the Device List tab Peripherals (see page 36) and, when the tab opens, click the tab. Whether Device Peripherals you navigate to the tab from an encoder or a decoder, the functionality is the Peripherals same.
  • Page 51 Pass-through mode In this mode, data received by a device (input) is transmitted over the network using TCP/IP and then converted back to serial data by a second device (output). Data flow is fully bidirectional and is independent of whether the VN-Matrix device is an encoder or decoder. Pass-through data cannot be recorded.
  • Page 52 Mouse & Keyboard Control VNM 250 products have the capability to forward mouse and keyboard information from a figure display device to a source device (see on page 42). This allows a source (PC) to be controlled remotely from the display location. The forwarding operation is configured automatically and the display is connected to the source from which video is currently being streamed.
  • Page 53 License tab Figure 28. License Tab Device License — for a VNM 250 device, the license features are fixed and cannot be modified. VNM 250 • VNM 250 GUI Overview...

  • Page 54: Encoder Tabs

    Encoder Tabs Device tab figure 29 Figure 29. VN-Matrix Encoder Device Tab Clicking an encoder on the Device List page (see page 36), opens the Encoder Device tab, which also has the tabs. The tabs Upgrade Peripherals Accounts Alarms are no longer available. There are three additional links ( , and videoPort0 audioPort0...

  • Page 55: Video Stream Input Configuration

    is a read-only field that reports which of the (by default) or Data Interface CAT 5 • connectors is currently active on LAN 2. (Time to Live) defines the number of hops multicast traffic makes Multicast TTL • between routed domains when it exits a source. (figure , on the previous page) —...
  • Page 56 shows the name of the display currently connected to the loop-through EDID (D) Monitor video connector. The reported EDID drop down allows selection of the EDID that the encoder reports to the source device. Selecting Transparent mode reports the EDID from the currently connected monitor.

  • Page 57: Managing Compression And Bandwidth Settings

    Managing Compression and Bandwidth Settings From the tab, click on the tab: Configure Bandwidth Bandwidth tab Figure 31. Video Bandwidth Tab The VNE 250 can apply various types of compression to an input source in order to reduce the volume of source data streamed across the network. In addition, various parameters are provided to manage and, if necessary, limit the amount of data flow to ensure that the available network bandwidth is not exceeded.
  • Page 58 When the fader is set to , the bit rate depends on the complexity (detail and unlimited motion) of the source image. As the fader is adjusted to reduce the maximum bit rate, the encoder progressively drops frames in order to limit the instantaneous bit rate. The number of frames dropped depends on the source image complexity.
  • Page 59 Video quality and Bandwidth panel — advanced control Figure 34. Bandwidth Tab: Video Quality and Bandwidth Panel panel (click , if necessary) provides a Video Quality and Bandwidth More Detail greater degree of control over the encoder compression settings. These controls are divided into two main categories: Video Quality •...
  • Page 60 Bandwidth panel Figure 35. Bandwidth Tab: Video Quality and Bandwidth Panel The VNE 250 can apply various control modes to manage the bit rate. These control modes are selected in the drop-down list. Mode — no bandwidth management policy is followed apart from the underlying None •...
  • Page 61 Video Setup tab To access the tab from the tab, click on the tab and, Video Setup Bandwidth Configure when that opens, click on the tab. The tab disappears and the Video Setup Bandwidth tab is highlighted. Video Setup Figure 36. Video Setup Tab This tab provides access to advanced functions that do not be needed in a typical setup.

  • Page 62: Audio Stream Configuration

    Audio Stream Configuration Configure (AudioPort0) tab To access the (AudioPort0) tab, click on the tab and, when that opens, Configure Device click on the link in the Configuration panel (see figure , on page 46). AudioPort0 Figure 37. Configure (AudioPort0) Tab The VNM 250 product range supports both program and return audio.

  • Page 63: Audio Input Selection

    The following compression values are supported: Compression Stereo Audio AC-3 Audio no compression 24 bit native data (2975 kbps) 24 bit native data (2975 kbps) pack 24 bits 24 bit data, full sample rate 16 bit data, zeros run length (2250 kbps) encoded (430 kbps) pack 20 bits...
  • Page 64 (return audio) — a return audio source can be enabled using the Analog Output Level • drop-down list. When enabled, return audio originates from a Return Audio Source decoder that is receiving the program audio from this encoder. NOTE: The decoder return audio setting must also be enabled. This drop-down list is populated only when a program audio connection has been made to the decoder.
  • Page 65 In this mode, data received by an encoder is transported to the decoder, along with video and audio, as part of the source stream. Data transport in this mode is unidirectional and is capable of being recorded and played back by the VNM Recorder and VNR 100 devices. Two types of data are supported: Serial RS-232 data •...

  • Page 66: Decoder Tabs

    Decoder Tabs Device tab Select a decoder in the tab and click to open the decoder page. Device List Device Figure 40. Decoder Device Tab , and tabs are available. The Device List Device Upgrade Peripherals Accounts tabs are no longer available. The decoder tab is split into four panels: Alarms Device...

  • Page 67: Output Configuration

    is a read-only field that reports which of the (by default) or Data Interface CAT 5 • connectors is currently active on LAN 2. (Time to Live) defines how many hops multicast traffic makes between Multicast TTL • routed domains when it exits a source. If the TTL is not properly configured, information that is to be sent back to a corresponding encoder may fail to function correctly.
  • Page 68 Select to enable the source image to be scaled to the required resolution and Scale • frame rate as defined by or the output format that is selected. Monitor Fixed NOTE: Scaling is disabled when the output format is set to Auto control allows the display output of multiple decoders to be coordinated Genlock...
  • Page 69 Assigning a video source stream In a system with multiple encoders, each decoder in that system potentially has access to multiple video streams. To assign a specific source stream to a decoder select one of the available source streams from the video source drop-down list (see the figure to the right).
  • Page 70 Decoder video bandwidth tab To access the video tab from the tab, click the link and, in the Bandwidth Device Display0 tab, click the link. Display video Figure 42. Video Bandwidth Tab This page provides statistics on the video stream and allows the decoder video buffer to be monitored and configured, if necessary.
  • Page 71 To synchronize channels, either between video and audio on one device or between video channels on multiple devices, the frame delay should be set to 6 and the channel delay to 0. Valid Delay settings can be determined by setting values then checking the Pipeline Status Meter.
  • Page 72 Figure 43. Audio Bandwidth Tab Audio output selection (Audio Control panel) Select the appropriate check boxes to output the received audio stream to the port, HDMI output port, or both. The HDMI output level cannot be controlled and is equal to Analog the level seen on the encoder device.
  • Page 73 Decoder audio connection fields The decoder audio connection fields operate in the same ways as the video connection fields (see Decoder video connection fields on page 63). Decoder data Bandwidth tab To access the data tab from the tab, click the link and, in the Bandwidth Device...
  • Page 74 Decoder data buffer The decoder data buffer operates in the same ways as the video buffer (see Decoder video buffer on page 62). NOTE: The frame delay setting reflects the value that is set in the video buffer and cannot be adjusted. Decoder data connection fields The decoder data connection fields operate in the same ways as the video connection fields (see...

  • Page 75: Configuration With The Vnm 250 Gui

    Configuration with the VNM 250 GUI This section provides information about configuring the VN Matrix system with the VNM 250 GUI control interface. NOTE: The VNM 250 GUI control interface should only be used with small systems (10 devices or fewer). For larger systems, the VNM Enterprise Controller must be used.

  • Page 76: Configuring Encoder Video

    Configuring Encoder Video In the panel, click on (see figure 47, Configuration VideoPort0 Figure 47. Device Configuration Panel tab opens with video options. Configure Figure 48. Configure Tab (Video Options) Ensure the is set to (see figure 48, Input Channel auto Set the for the digital video input and the...

  • Page 77: Managing Compression And Bandwidth Settings

    Managing Compression and Bandwidth Settings Open the encoder tab. Bandwidth For more information about the Bandwidth tab, see page 49. Figure 49. Encoder Video Bandwidth Tab When this page opens, only the panel is visible. NOTE: Bandwidth Management Click the button to display the More Detail Video Quality...

  • Page 78: Bandwidth Management - Advanced Control

    Bandwidth Management – Advanced Control If necessary, click to open the panel: More Detail Video Quality Bandwidth Figure 51. Encoder Video Bandwidth Tab Advanced Control Spatial compression luminance and chrominance settings Set the (see figure 51, ) and ) values from the Luminance Chrominance appropriate drop-down list.

  • Page 79: Configuring Encoder Audio

    Configuring Encoder Audio Click on the tab. Device In the panel, click on (see figure 52, Configuration audioPort0 Figure 52. Device Configuration Panel tab opens with audio options. Configure Figure 53. Configure Tab (Audio Options) Select the audio source by checking either the box (see figure 53, HDMI Analog...

  • Page 80: Configuring Encoder Data

    If RTP multicast source streaming is required, select (see Multicast Enable figure 53,  on the previous page). If RTP unicast is required, ensure the box is not selected. ATTENTION: • Use the same transport type for all streams. Check that the Multicast Enable setting on the data tab is the same as that on the video (see step 14...

  • Page 81: Configuring A Vnd 250

    If RTP multicast source streaming is required, select the box (see Multicast Enable figure 55, on the previous page). If RTP unicast is required, ensure the box is not selected. ATTENTION: • Use the same transport type for all streams. Check that the Multicast Enable setting on the data tab is the same as that on the video (see step 14...

  • Page 82: Configuring The Decoder Display

    Configuring the Decoder Display In the panel, click on (see figure 57, Configuration display0 Figure 57. Device Configuration Panel tab opens with display options (see figure 58). More information about the Display Display tab can be found on page 59. figure 58 Figure 58.

  • Page 83: Monitoring The Decoder Video Bandwidth

    If required, use the drop-down list (see figure , on the previous Framelock Ref page) to set up membership of a decoder genlock group (see Framelock Ref on page 60). Select a video source from the drop-down list ( Source If required, select the check boxes ( audio...

  • Page 84: Configuring The Decoder Audio

    Configuring the Decoder Audio Figure 61. Decoder Audio Bandwidth Link In the tab, ensure that the check box (see figure 61, ) is selected. Display Audio Click the bandwidth link ( ). The (audio) tab opens. This is the same audio Bandwidth as the...

  • Page 85: Configuring The Decoder Data

    Configuring the Decoder Data Figure 63. Decoder Data Bandwidth Link In the tab, ensure that the check box (see figure 63, ) is selected. Display Data Click the bandwidth link ( ). The (data) tab opens. This is the same data Bandwidth as the...

  • Page 86: Custom Input And Output Modes

    Custom Input and Output Modes For most applications, the source input of the VNE 250 is set to auto mode. This enables the encoder to detect the electrical and timing characteristics of the input signal and determine the exact source type. It then invokes the appropriate input parameters for optimum processing of that source.
  • Page 87 Figure 66. Advanced Video Setup For most source types select from the drop-down list (see figure 66, auto mode allowing full auto-detection of the source. To apply a fixed input mode, select the required mode from the drop-down list and click or the tab.

  • Page 88: Custom Input Modes

    (RGB/YPrPb) (see figure on the previous page) — Because of the Color space • similarity between analog RGsB (sync on green) and component YPrPb signals, sources using these formats may not auto-detect correctly. RGsB and YPrPb sources have different color spaces and if the wrong setup is applied the resulting image, although stable, has a red or green color cast.
  • Page 89 Fine-tune the custom input mode. NOTE: After the custom input mode is created for the VNE 250, you may need to create a custom output mode to match. TIPS: It is recommended that: • When creating a custom input mode, monitors are connected to both the video loop-out of the VNE 250 and the video output of the VND 250.
  • Page 90 Select a source type similar to the desired source type in the field of the Name User panel (see figure 68, ). If an existing (incorrect) mode was detected Source Format and displayed in the field of the panel, select that mode currentMode Device Status from the drop-down list.
  • Page 91 Enter the active horizontal resolution in the field and the active vertical resolution HSize in the field (see figure on the previous page). VSize Copy the values in the fields of the digFirstPixel digFirstLine Device Status panel to the fields (see figure ¢...

  • Page 92: Custom Output Modes

    Custom Output Modes The decoder tab allows you to create custom video output formats for displaying Format decoded video data streams. One of the issues encountered when some graphics sources are used in conjunction with VN-Matrix encoder and decoder systems is that the encoder often produces a loop-through image and states that it has detected a valid input mode.
  • Page 93 Click and then click Update Save Formats From the source device that is supplying the encoder, change the resolution and allow the encoder to display the image on the loop-out. This forces the VN-Matrix to change both input and output modes. Change the source back to the original resolution.
  • Page 94 Write down the values that are reported for: Active area width • Active area height • Frame rate • Total line count • Total pixels per line • These values are required in the next section. Entering the timing values in the VN-Matrix web GUI Return to the VN-Matrix GUI and open the decoder tab.
  • Page 95 Calculate the horizontal back porch value. This value is calculated with the formula: total pixels per line – (active pixels in width + horizontal left border + horizontal right border + horizontal front porch + horizontal sync width) Using the values from the example in step 4, above, this equates to: 1800 –...

  • Page 96: Upgrading Firmware

    Upgrading Firmware Extron may issue firmware upgrades for the VNM 250 in order to make new functionality available. Details of the latest firmware release are published on www.extron.com. ATTENTION: • The encoder and decoder each have a different firmware file. •...

  • Page 97: Uploading The Firmware File To The Vnm 250 Device

    Uploading the Firmware File to the VNM 250 Device Log in to the web interface (see VNM 250 GUI Login on page 34). The GUI opens to page. Device List Click on the VNM 250 unit to be upgraded. The page for that unit opens.

  • Page 98: Configuring Kvm Functionality

    Configuring KVM Functionality KVM functionality permits remote collaboration between different endpoints on the network by allowing a mouse and keyboard connected to the decoder to control a PC connected to the encoder. Both the VND 250 and VNE 250 units must be configured. Before starting, ensure that a mouse and keyboard have been connected to the VND 250 and a PC has been connected to the VNE 250 (see USB Ports...

  • Page 99: Rs-232 Pass-Through Configuration

    RS-232 Pass-through Configuration The Pass-thru Control port on the rear panel of the encoder (see figure page 13), or decoder (see figure 7,  on page 13) is used for RS-232 pass-through communications, allowing a control device connected to one VNM 250 unit (the server) to control remote devices connected to other VNM 250 units (clients).

  • Page 100: Front Panel Menu Configuration

    Front Panel Menu Configuration This section describes how to configure the VNM 250 units, using the front panel menu: Front Panel Menu Overview Configuring the VNE 250 Encoder Configuring the VND 250 Decoder Front Panel Menu Overview The default menu screens display whenever the menu is not actively accessed. They are read-only and provide information about the current status of the encoder (see below) or decoder.

  • Page 101: Top Level Menu

    Input Controller Input [HDMI/VGA/None] Controller Input [Status] [Resolution] Controller Input [IP Address] [Format] Connection [Transport] Device [Firmware Version] [Status] [Device Serial Number] Connection [Transport] Device [Firmware Version] [Bit rate] [Name] Connection [n] [Transport] Device LAN2 [Connection count] [IP Address] Device LAN2 Connection Device...

  • Page 102: Encode Config Submenu

    Encode Encode Config Submenu below. NEXT MENU Con g MENU OSD Submenu on page 95. NEXT MENU Network Submenu on page 95. Network NEXT MENU Input Submenu on page 97. Input NEXT MENU EDID EDID Submenu on page 98. NEXT MENU Test Test Pattern Submenu...

  • Page 103: Osd Submenu

    OSD Submenu The OSD submenu allows you to determine what information is overlaid on the loop-through display. NEXT NEXT MENU [Disable] Disable Device Name Stream Name Both Figure 77. VNE 250 Encoder OSD Submenu In the main screen, press to open the submenu.
  • Page 104 Read Only Editable More than 3 seconds Network LAN1-Control [IP, SM] LAN1-Control [IP, SM] NEXT NEXT MENU [IP address] [IP address] Less than NEXT 3 seconds More than 3 seconds LAN2-Stream [IP, SM] LAN2-Stream [IP, SM] NEXT [IP address] [IP address] Less than NEXT 3 seconds...

  • Page 105: Input Submenu

    — follow steps 1 through 4 of the Control section on the previous page. IP address • — follow steps 1 through 4 of the Control section. Subnet mask • — follow steps 1 through 4 of the Control section. Gateway •...

  • Page 106: Edid Submenu

    In the main screen, press to open the screen. Input Next Input Source In the screen, use either rotary encoder to select the video source: Input Source (selects HDMI whenever a digital source is detected) auto • (digital) HDMI • (analog) •...

  • Page 107: Test Pattern Submenu

    Use left rotary control to select the , or ) and the location Transparent Stored Fixed . The choices available in the EDID name selection depend on which location EDID name you chose: — if you select Transparent, the EDID from the locally connected Transparent •...

  • Page 108: Reset Submenu

    Reset Submenu submenu allows you to reset many parameters to the factory defaults. It also Reset allows you to run the Sanitize process. Reset Reset [Factory IP] NEXT MENU [Activate] NEXT Are you sure? [Yes] NEXT System Reset in progress Figure 82.

  • Page 109: Configuring The Vnd 250 Decoder

    Configuring the VND 250 Decoder Default Menu Screens On powering the unit up, or if the menu is not accessed for 30 seconds, the front panel LCD shows the default menu screens. These are a series of screens that show the current status and configuration of the unit.

  • Page 110: Top Level Menu

    Top Level Menu To access the top level menu: Press the button to access the first item in the top level menu ( Menu Decode Config Continue pressing the button to scroll through all the available top level options Menu When the desired option appears in the LCD window, press the button to select Next...

  • Page 111: Decode Config Submenu

    Decode Config Submenu Config submenu allows you to: Decode Select a stream. • the splash screen. Enable Disable • Decode Select None or Select Stream choose from list of NEXT MENU available streams [Available streams] NEXT Splash [enable] NEXT Figure 85. VND 250 Decoder Decode Config Submenu In the main screen, press...

  • Page 112: Osd Submenu

    OSD Submenu submenu allows you to determine what information is overlaid on the output display. NEXT NEXT MENU [Disable] Disable Device Name Stream Name Both Figure 86. VND 250 Decoder OSD Submenu In the main screen, press to open the submenu.
  • Page 113 Read Only Editable More than 3 seconds Network LAN1-Control [IP, SM] LAN1-Control [IP, SM] NEXT NEXT MENU [IP address] [IP address] Less than NEXT 3 seconds More than 3 seconds LAN2-Stream [IP, SM] LAN2-Stream [IP, SM] NEXT [IP address] [IP address] Less than NEXT 3 seconds...
  • Page 114 Stream editing screen allows you to adjust the following properties of the LAN2-Stream streaming network: — follow steps 1 through 4 of the Control section on the previous page. IP address • — follow steps 1 through 4 of the Control section.

  • Page 115: Output Submenu

    Output Submenu submenu allows you to: Output decoding Enable Disable • Power save Active Inactive • Scale the output resolution • Select: Enable Output Output Disable NEXT MENU Test [Enable] Standby NEXT Select: Active Power save Disabled [Active] NEXT Select: None Scale mode Display [None]...

  • Page 116: Video Wall Submenu

    Use either rotary encoder to select from: — no scaling. The output resolution and frame rate are the same as the input None • stream. — the output resolution and frame rate are based on a supported Display • resolution from the display. —...

  • Page 117: Test Pattern Submenu

    In the main screen, press to open the screen. Video wall Next Set wall size Use the left rotary encoder to select the horizontal number of displays in the Video wall array. Use the right rotary encoder to select the vertical number of displays in the Video wall array.

  • Page 118: Genlock Submenu

    Genlock Submenu submenu allows you to enable or disable genlock and to determine whether Genlock the display is a master or slave. Select: Enable Genlock Genlock Disable NEXT MENU [Enable] Disable Enable NEXT NEXT Select: Frame lock Ref None [None] [list of available devices] NEXT Figure 91.
  • Page 119 In the Options screen, use the left rotary encoder to select which type of reset Reset you want. You can choose Factory IP Sanitize — restores the following parameters to the factory default: Factory IP IP address • Subnet mask •...

  • Page 120: Alarms

    Alarms Alarm Types The VNE 250 and VND 250 generate alarms in response to a range of error conditions. Alarm Description Fault Description Alarm Type No source No source is connected at the input. Critical, Reporting Bad Source Sync An input source is connected but the signal Critical, timing is not recognized.
  • Page 121 Alarm Description Fault Description Alarm Type No Decoder Video A stream is assigned but the decoder is not Warning, Data receiving any video data. Reporting No Decoder Mode A video stream is assigned but the decoder Warning, does not recognize the format. (The decoder Reporting cannot output the current input stream.) No Source Report...

  • Page 122: Alarm Handling

    Alarm Description Fault Description Alarm Type Over Temperature The hardware is too hot and is likely to Warning, behave erratically. Reporting Bad Device The Device is not properly communicating Critical, with the controller. Reporting RTP stream holdoff The RTP data stream has been temporarily Critical, disabled due to excess packet drops.

  • Page 123: Troubleshooting

    Troubleshooting If you have followed the procedures on the preceding pages, you should by now have set up at least one VNE 250 encoder and one VND 250 decoder, and be able to display the source (encoder) signal on the display (decoder). If not, this section helps to diagnose most problems you may encounter.

  • Page 124: Front Panel Status Indicators

    Front Panel Status Indicators Name Color Function Orange Control Indicates the status of the control network port: Fully lit or Flashing intermittently — control data is being transmitted or received by the port. Unlit — no data or no network connection detected. Orange Stream Indicates the status of the active network port (streaming):...

  • Page 125: Default Menu Screens (Encoder)

    Default Menu Screens (Encoder) Input Controller Input [HDMI/VGA/None] Controller Input [Status] [Resolution] Controller Input [IP Address] [Format] Connection [Transport] Device [Firmware Version] [Status] [Device Serial Number] Connection [Transport] Device [Firmware Version] [Bit rate] [Name] Connection [n] [Transport] Device LAN2 [Connection count] [IP Address] Device LAN2...

  • Page 126: Controller Web User Interface

    Controller Web User Interface When troubleshooting using the Web UI, the following links may provide useful information about the cause of the problem: Encoder Device tab (page 46) Decoder Device tab (page 58) Alarms tab (page 38) Alarm Logs tab (page 39) SNMP (page 40)

  • Page 127: Device Not Listed In The Device List Page

    Device Not Listed in the Device List Page Cause Check The device is not If the front panel LEDs are unlit and the front panel LCD menu is not cycling through powered on. the default menu, the unit is not powered on. Check that the power supply is connected to the rear panel receptacle and that the Power IEC cord from the power supply is connected to a suitable power source (see...

  • Page 128: Decoder - Problems With Viewing The Decoded Image

    Cause Check The loop-through Connect the source directly to the display and check that an image is shown. display is incompatible with the input. The VNE 250 does not The VNE 250 accepts VGA, DVI (with appropriate adapters), or HDMI signals. Other support the input signal video types are not recognized and cannot be streamed.

  • Page 129: Program Audio Problems

    Cause Check Power Save mode is The decoder display enters power save mode if the stream assigned for decoding is enabled. no longer available and the power save mode is enabled in the decoder front panel Output Submenu (see page 107) . No stream is assigned.

  • Page 130: Return Audio Problems

    Return Audio Problems Return audio requires settings to be made on both the encoder and decoder. Cause Check The return audio input Ensure the check box is selected on the Analog input enable decoder has not been enabled Return audio configuration page (see on page 64).

  • Page 131: Reference Material

    Reference Material This section provides information about: Supported EDID Modes • VN-Matrix System Port Usage • Supported EDID Modes Resolution Refresh Audio File Size 800x600 60 Hz 128 bytes 1024x768 60 Hz 128 bytes 1280x720 60 Hz 128 bytes 1280x768 60 Hz 128 bytes 1280x800...

  • Page 132: Vga

    Resolution Refresh Audio File Size 1680x1050 60 Hz 2-Ch 256 bytes 1920x1200 60 Hz 2-Ch 256 bytes 2048x1080 60 Hz 2-Ch 256 bytes 480p 60 Hz 2-Ch 256 bytes 576p 50 Hz 2-Ch 256 bytes 720p 50 Hz 2-Ch 256 bytes 720p 60 Hz 2-Ch...
  • Page 133 Port Transport Usage TFTP Server, for firmware upgrades. HTTP data for communication between the web browser and the Enterprise Controller. Value is user definable; the default is 80. Real-time streaming protocol (RTSP) server. 5432 Enterprise Controller outgoing and incoming control messages used on the device acting as controller to communicate with other VN‑Matrix devices.

  • Page 134: Sis Commands

    SIS Commands This section provides the following information about the SIS commands that can be used to configure the VND 250 and VNE 250: Introduction to SIS • Symbols used in this Guide • Error Messages • Command and Response Table for SIS Commands •...

  • Page 135: Error Messages

    — Carriage return with line feed (Hex: 0D0A — Carriage return without line feed (Hex: This character can be used interchangeably with the pipe character ( • — Space character (Hex: — Escape key (Hex: This character can be used interchangeably with the upper-case character.

  • Page 136: Command And Response Table For Sis Commands

    Command and Response Table for SIS Commands Command ASCII Command Response Additional Description (host to unit) (unit to host) Network Set DHCP EX57^ X57^ X57^ = NIC card number LAN 1 = LAN 2 = = DHCP status = disabled (default) = enabled Query DHCP EX57^ Set IP address...
  • Page 137 Command ASCII Command Response Additional Description (host to unit) (unit to host) General Query Firmware Firmware version as x.xx.xxx x.xx.xxx version (major.minor.build) Query Part Part number Pno xx-xxxx-xx Number (encoder) 60-1274-01 (decoder) 60-1275-01 Query Model Model name • • Matrix Name •...

  • Page 138: Mounting

    Mounting This section provides information on the following: Choosing a Suitable Location for Mounting • Environmental Requirements • Mounting Procedures • Choosing a Suitable Location for Mounting The VNM 250 is designed to be used either as a free-standing unit or mounted in a 19-inch rack using optional mounting kits.

  • Page 139: Humidity And Water

    Humidity and water Do not install or operate the VNM 250 in an area: where the ambient relative humidity exceeds 85% • that is prone to condensation • near water or in a location that may be prone to water •...
  • Page 140 Extron Electronics makes no further warranties either expressed or implied with respect to the product and its quality, performance, merchantability, or fitness for any particular use. In no event will Extron Electronics be liable for direct, indirect, or consequential damages resulting from any defect in this product even if Extron Electronics has been advised of such damage.

This manual is also suitable for:

Vnd 250Vne 250

Table of Contents
