For tower models, install the tower bezel.
•
For rack models, install the security bezel.
Installing an SSD module
Procedure
1.
Back up all server data.
2.
Do one of the following:
•
For tower models, open and remove the tower bezel.
•
For rack models, if installed, remove the security bezel.
3.
Power down the server.
4.
Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server .
5.
Do one of the following:
•
For tower models, place the server on a flat, level surface with the access panel facing up.
•
For rack models, extend the server from the rack.
6.
Remove the access panel.
7.
Remove the air baffle.
IMPORTANT:
For management and monitoring of the SSD modules, use the HPE Smart Storage
Administrator.
8.
Install the SSD module on the M.2 SSD enablement board.
9.
Install the M.2 SSD Enablement Board in slot one of the PCIe riser cage.
10. Install the air baffle.
11. Install the access panel.
12. Do one of the following:
•
If the server is in a tower configuration, return the server to an upright position.
•
If the server is in a rack configuration, slide the server into the rack.
13. Connect each power cord to the server .
14. Connect each power cord to the power source.
126
