Chapter 2: Jumpers and Connectors

Jumpers

H/W AT/ATX Mode Selection

Connector type: 1x3 3-pin header
Connector location: ATMODE
1 3
Pin Settings
1-2 ATX Mode
2-3 AT Mode
2-3 On: default
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.

RTC CMOS Clear Selection

Connector type: 1x3 3-pin header
Connector location: CLRTC1
1 3
Pin Settings
1-2 Normal
2-3 Clear CMOS
1-2 On: default
9
NEX 912 User Manual
